FALCON EYE OMEGA 1K Kurzanleitung

OMEGA 1K
FHH0141
EN SPECIFICATION
OPERATION LIGHT
MODE OUTPUT
TURBO
1000 lm
HIGH
600 lm
MEDIUM 300 lm
LOW
200 lm
ULTRA LOW
60 lm
STROBE
-
S.O.S. -
BATTERY 16340 Li-Ion 3,7V 700 mAh
CHARGING TIME 2 h
WEIGHT 87 g
DIMENSIONS 74 x 29 x 24 mm
IP RATING IPX4
IMPACT RESISTANCE 1 m
Thank you for choosing a Mactronic
maintenance guarantee the product's high durability and reliability.
Please read the operating manual and keep it for reference, because
it contains important information about safety and operation of the
product.
NOTICE
It is not recommended to use the flashlight for purposes other than
intended. The manufacturer explicitly voids the warranty if the fla-
shlight has been used for other than its intended purpose.
FLASHLIGHT OPERATION
Attention! The flashlight comes with a factory-installed battery
contact separator, which must be removed from the battery com-
partment. To remove the separator, unscrew the tail cap, take out
the battery contact separator inside, and then screw the tail cap
back into place.
To turn on the flashlight, press the button located on the body. The
flashlight will start in HIGH mode. Subsequent presses will switch
the modes in the following order: HIGH → MEDIUM → LOW →
ULTRA LOW → OFF. If the time between presses exceeds 10 se-
conds, the flashlight will turn off with the next button press. To acti-
vate the TURBO mode at any time, quickly press the button twice – a
double-click. The light will return to the previous mode after the next
button press or after 30 seconds.To activate the FLASHING mode,
hold the button for 3 seconds. Subsequent presses will now switch
the flashlight modes in the following order: FLASHING → S.O.S. →
OFF. During operation, the flashlight indicates the battery charge
status via a hidden LED in the button: Green – fully charged Flashing
red – battery low.
REPLACING THE BATTERY
To charge the flashlight, connect the included USB cable to a power
source: USB-5V/1A. Connect the other end of the cable, equipped
with a USB-C plug, to the flashlight's charging port hidden behind
the rubber cover. The active charging process will be indicated by a
red LED in the switch. When the LED changes from red to green, it
indicates the charging process is complete.
CAUTION!
Make sure you use only genuine parts designed for Falcon Eye
shlight. Using spare parts from other manufacturers may affect the
quality and parameters of the product. The rechargeable batteries
used in this product may be subject to re-processing. Pursuant to
the EU's WEEE regulation, storage batteries must not be disposed
of with normal household waste. Instead, they must be disposed of
at designated battery collection points. Contact the management of
your local waste collection company for advice on the required ways
and types of re-processing, or other instructions.
BEAM RUN
DISTANCE TIME
90 m 30 sec
70 m 1 h 30 min
55 m 2 h 30 min
25 m 6 h
20 m 12 h
- -
- -
product. Proper operation and
®
®
GENERAL INFORMATION
Modifications and repairs:
Modifications and repairs, other than those authorized by Mactro-
nic , are prohibited.
®
Mactronic's warranty:
®
Flashlight has a 2-year warranty on defects in material and
workmanship. Warranty does not cover: products bearing the cha-
racteristics of normal wear and tear, rust, altered and modified,
improperly stored, damaged as a result of falls, negligence, leaking
batteries and by use for which it was not intended.
WARRANTY CARD
The warranty card can be downloaded at www.falconeye.pl
USING AND HANDLING THE BATTERY
To reduce the risk of fire, electrocution or other bodily harm, careful-
ly read the flashlight's operating manual.
- Always make sure the battery's polarity is correct.
- Remove the batteries if the flashlight is stored for extended time.
- Do not recharge alkaline batteries.
- Do not dispose of the batteries in fire.
- Keep the batteries out of reach of the children.
- Do not force the batteries open.
- Keep the flashlight away from UV radiation, humidity and chemical
products.
DE SPEZIFIKATION
LEUCHTMODI LUMEN
TURBO
HIGH
MEDIUM
LOW
ULTRA LOW
STROBE
S.O.S.
HAUPTEINSPEISUNG 16340 Li-Ion 3,7V 700 mAh
LADEZEIT 2 h
GEWICHT 87 g
GRÖSSE 74 x 29 x 24 mm
IP-SCHUTZART IPX4
STOSSCHUTZ 1 m
Vielen Dank, dass Sie sich für ein Mactronic
haben. Eine ordnungsgemäße Bedienung und Wartung gewährleistet
eine hohe Lebensdauer und Zuverlässigkeit. Bitte lesen und befolgen
Sie dieses Handbuch zum späteren Gebrauch, da es wichtige Informa-
tionen zum sicheren Betrieb und Nutzung enthält.
HINWEIS
Bestimmungswidrige Nutzung der Taschenlampe wird nicht empfoh-
len. Der Hersteller nimmt die Garantie ausdrücklich zurück, wenn die
Taschenlampe bestimmungswidrig benutzt wird.
BEDIENUNG DER TASCHENLAMPE
Achtung! Die Taschenlampe ist mit einem werkseitig installierten
Batteriekontaktseparator ausgestattet, der aus dem Batteriefach
entfernt werden muss. Um den Separator zu entfernen, schrauben
Sie die Endkappe ab, entnehmen Sie den Batteriekontaktseparator
aus dem Inneren und schrauben Sie die Endkappe wieder an ihren
Platz.
Um die Taschenlampe einzuschalten, drücken Sie die Taste am Gehäu-
se. Die Taschenlampe startet im HIGH-Modus. Weitere Tastendrücke
wechseln die Modi in folgender Reihenfolge: HIGH → MEDIUM → LOW
→ ULTRA LOW → OFF. Wenn der Abstand zwischen den Tastendrüc-
ken 10 Sekunden überschreitet, schaltet sich die Taschenlampe beim
nächsten Tastendruck aus. Um den TURBO-Modus jederzeit zu akti-
vieren, drücken Sie den Schalter zweimal schnell – Doppelklick. Die
Lampe kehrt nach dem nächsten Tastendruck oder nach 30 Sekunden
fla-
in den vorherigen Modus zurück. Um die Taschenlampe im FLASHIN-
G-Modus zu starten, halten Sie die Taste 3 Sekunden lang gedrückt.
Weitere Tastendrücke schalten die Modi der Taschenlampe nun in
folgender Reihenfolge um: FLASHING → S.O.S. → OFF. Während des
Betriebs zeigt die Taschenlampe den Akkuladestand über eine im
Schalter versteckte LED an: Grün – Taschenlampe aufgeladen Blin-
kendes Rot – Taschenlampe entladen.
LEUCHTWEITE
1000 lm 90 m
600 lm 70 m
300 lm 55 m
200 lm 25 m
60 lm 20 m
- -
- -
®
LEUCHTDAUER
30 sec
1 h 30 min
2 h 30 min
6 h
12 h
-
-
-Produkt entschieden
