Once finished using the unit, it is advisable to wrap the
power cord so as to ensure a better cleaning and to avoid
the risk of damage. For cleaning, follow the instructions
in section "Cleaning".
Do not immerse the motor unit in water or other liquids;
clean it with a damp cloth.
This machine is not suitable for juicing cereals
or sugar cane.
DESCRIPTION OF PARTS SW11
1. Food presser
4. Filter
7. Juice and Pulp jug
ASSEMBLY
- Place the main unit (6) on a flat and stable
surface.
- Step A: place the container (5), fitting it to
motor unit (6) as shown in Fig B). Ensure that the parts they fit securely.
- Step B: Place the filter (4) in the container. To lock in position, match the arrow on the
filter with the symbol "Lock" on container (Fig. B).
- Step C: Insert the auger (3) inside the filter (4), making sure it is securely anchored to the base.
- Step D: Place the cover (2) on the container and turn it clockwise to lock it in place.
CAUTION: If top cover (2) has not been properly locked, the device doesn't work.
- Place the round tray and the food presser (1) over the lid (2). Put juice collector (7) in correspondence of
the outlet nozzle of juice; then place pulp jug (7) under the output pulp spout.
- The slow juicer is assembled and ready for use.
NOTE: the container (5) is equipped with a rubber plug which is mounted in
correspondence of the waste outlet. Make sure the plug is inserted BEFORE USE (as
shown in Figure A). At the same time, remove the rubber plug during cleaning to remove
any residue that may be deposited inside the chamber
FIRST USE
Install the appliance several times without plugging it or adding any fruits or vegetables. Follow these steps to
practice with the unit. Carefully wash all the parts that will come in touch with food such as the two
containers, the chamber, the lid, the micro-mesh filter and the auger. Other accessories with electrical parts,
such as the main unit, must be cleaned with a damp cloth and dry immediately.
OPERATING THE UNIT
1. Perform the installation according to the instructions in the previous paragraph.
2. Wash, clean and cut fruits or vegetables coarsely, taking care to remove the hard parts such as the pit or
large seeds.
3. To switch on the unit, put the power button on 1.
4. Insert fruits into the slot pushing them gently with the presser (1).
5. The slow juicer will pour the juice into the glass discarding the pulp in the container.
6. Enter foods until you get the desired amount of juice.
CAUTION: Do not use for more than 10 minutes continuously. Remember to take a 5 minutes break
after every full process.
2. Top cover
5. Container
8. Brush
3. Auger
6. Main unit
9. ON and reverse button
