muuto LINEAR SYSTEM MIDDLE MODULE Montageanleitung Seite 2

CONTENT — INDHOLD — INHALT — CONTENU — CONTENIDO CONTENT — INDHOLD — INHALT — CONTENU — CONTENIDO
x 2 x 2
A x 36 B x 32
x 2 x 2
x 1 x 4
ASSEMBLING YOUR LINEAR SYSTEM:
Step 2a )
Assemble the Linear Middle
Module(s) and attach a set of
Linear Connecting Legs.
Then connect to Step 1.
Step 1 )
Assemble the Linear End or, Step 2b )
Module and attach a set of Assemble the Linear End Module.
Linear Connecting Legs. Then connect to Step 1.
FOR CONNECTING END AND MIDDLE MODULES:
SEE CONNECTING LEGS MANUAL
CONFIGURATION 3
End Module Middle Module
240 cm / 94,5" 240 cm / 94,5"
Step 3 )
Assemble the Linear End Module.
Then connect to Step 2a.
End Module
240 cm / 94,5"
