UNPACKING INSTRUCTION
CAUTION! Carefully unpack the box upon receipt. Check the contents to ensure that all parts are present and have been
received in good condition. Notify the shipper immediately and retain packaging material if any parts appear damaged from
shipping or the package itself shows signs of mishandling. Save the package and all packaging materials. If the product must be
returned, it is important that the product is returned in the original factory box and packaging.
If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not switch it on immediately. The
arising condensation water might damage your device. Leave the device switched off until it has reached room temperature.
POWERSUPPLY
The label on the back/under side of the product indicates the mains voltage to which it must be connected. Check that the mains
voltage corresponds to this. Any other voltage than the one indicated may cause irreparable damage to the unit. The unit must
also be connected directly to the mains voltage and no dimmer or adjustable power supply may be used.
Always connect the device to a protected circuit (circuit breaker or fuse). Make sure the device has an appropriate
electrical ground to avoid the risk of electrocution or fire.
OPERATION
1.
Set each transmitter and receiver to the same universe. For this purpose, shortly press the recessed button on the
devices with a thin object. The selected universe is colour indicated by the LED indicator.
DMX Universe
1
2
3
4
5
6
7
2.
As soon as the transmitter receives a DMX signal, the status indicator switches to red. Shortly afterward, the status
indicators of the receivers start flashing green to indicate that the DMX signal is being received. The DMX-controlled
units can now be controlled via 2.4Ghz.
Colour
DMX Channels
Red
1 ~ 512
Green
1 ~ 512
Yellow
1 ~ 512
Blue
1 ~ 512
Magenta
1 ~ 512
Cyan
1 ~ 512
White
1 ~ 512
3
