PREFA
B
F
E
D
G
H
PREFA
120
TAURUS-PREFA | 231025 | www.innotech.at
C
A) 1x | TAURUS-BEF-10
B) 2x | Ø 84,5 x 13
C) 2x | Ø 87 x 13
D) 2x | M12x50 DIN913
E) 2x | M12 DIN9021
F) 4x | M12 DIN6923
G) 4x | 8,0 x 120 HBS Komprex
H) 4x | 8,0 x 220 HBS Komprex
~
