6a. WIRING - FLYING LEAD
Interconnection
of luminaires
is not permitted
Brown -
Braun
220-240V
Min.
Ø8mm
Max.
Ø13mm
CLOSING
7
1
Re-attach
dog clip
8
ANGLE ADJUSTMENT & LOCKING
-
Green & Yellow
Grün & Gelb
L
Blue -
50Hz
N
Blau
3
1
Loosen bolt
6b. WIRING - TERMINAL BLOCK
Interconnection
of luminaires
is not permitted
N
i
1.5mm² max.
If ferrulled
2
2
Max. 2 x 2.5mm²
V/Hz=
L
(1.5mm² - 2.5mm² cable only)
4
x2
1x CLICK = 5°
21LFT73668 - Rev A
Jan 2025
