The brush (12) can be mounted directly to the main housing (3), inserting the connector of the brush in
the suction port (5). To clean floor and carpet we suggest to attach the brush (12) to the aluminium tube
(9), and tube to the port (5).
-
To remove accessories press release buttons on aluminum tube, and on port (5).
TELESCOPIC TUBE The aluminum tube (9) is telescopic and its lenght can be changed depending on
user's need. Press button (8) and press or pull the upper part of tube to have the desired lenght.
ACCESSORY MULTIFUNCTION BRUSH
The brush (13) is suitable for vacuuming on textile and surfaces: sofa, car, bed,
pet hairs. It also features an integrated motor, that moves the brush, to collect
more dirt. We suggest to attach the brush (13) directly to the main housing
(3), inserting the connector of the brush in the suction port (5). In this way
you will have a powerful handy cleaner with multi-function brush.
ACCESSORY NOZZLE The nozzle (10) is suitable for vacuuming in
cracks, corners, tile joints and narrow places.
-
The nozzle (10) can be mounted directly to the main housing (3), inserting it in the port (5).
-
Add the aluminum tube if you want to reach far surfaces like the ceiling. Mount nozzle to the tube (9),
and the tube to the port (5).
MAINTENANCE AND CLEANING
EMPTYING THE DUST CONTAINER
When dust reaches maximum level inside the container (6), it is necessary to remove it.
To empty the container (6), bring the vacuum cleaner above a bin and press the container
open button (14). This button will open the door dropping all the dirt. It is recommended
to do this outdoors to avoid soiling the house when the dust comes out of the trash. Close the lid.
FILTERING SYSTEM MAINTENANCE
This vacuum cleaner is equipped with a metallic filter (19) and a HEPA filter (17),
capable of retaining particles and small organisms such as mites and pollens. In this
way the air re-emitted from the cleaner will be more healthy and clean. To maintain the
performance of the vacuum cleaner is recommended to clean the filters regularly.
Pull the container release button (15). This button is small and incorporated in the
housing of container near the battery. Pull soflty in direction of the battery. Pulling the
button, the container (6) detaches.
a) Take the HEPA filter (17) out of the container (6) and clean it as described below.
b) Lift up the handle that is below the HEPA filter, and gently rotate it clockwise to unlock the filtering
system that includes the metal mesh filter. Washthis part with running water
At least once a week, shake the HEPA filter in the bin to get the dirt out.
At least once every 2 months, carry out a more thorough cleaning: rinse HEPA filter nd metal filter and clean
container with a damp cloth and DRY ALL PARTS THOROUGHLY.
CAUTION: Do not use detergent to clean the filter or the filtering system. All the parts must be
completely dry before using the vacuum cleaner.
After cleaning:
-
Insert the filtering system (19) in the container (6) and rotate it anti-clockwise to block it.
-
Lower the handle and insert the HEPA filter (17) over the filtering system.
-
Mount the container (6) to the main housing (3).
BRUSH MANTAINANCE
It is recommended to periodically check the condition of the brush and if it is dirty it should be cleaned.
-
Take the motorized brush (12) and turn upside down.
-
On the left there is the lid blocking the rotating brush. Push it outwards.
-
Extract the rotating brush and clean it; use a vacuum cleaner or wash it with tap water and then dry it.
-
Clean the internal part of the brush (12) and the suction tube. Mount the brush.
13
