TRT Lighting Via Kurzanleitung

Via
LED
Disconnect luminaire from the supply when conducting
in-situ insulation resistance testing.
If the external flexible cable or cord of this luminaire
is damaged, it shall be exclusively replaced by the
manufacturer or his service agent or a similar
qualified person in order to avoid a hazard.
GB - Do not stare at operating lamp. May be harmful to the eyes.
FR - Ne pas xer la lampe en fonctionnement.
DE - Vermeiden Sie den direkten Blick auf die Lampe während
diese in Betrieb ist.
IT - Si prega di non guardare dentro la lampada accesa.
SE - Titta inte direkt in i lampan, detta kan skada ögonen.
ES - No mirar a la lampara durante su funcionamiento.
Puede causar daños en los ojos.
NL - Kijk niet in werkende lichtbron. Kan schadelijk zijn voor de ogen.
NO - Stir ikke på lyskildene da dette kan skade øynene.
PL - Proszę nie wpatrywać się we włączoną żarόwkę.
To może być niebezpieczne dla wzroku.
1
FLANGE MOUNT ROOT MOUNT
165
dia.
CABLE
ENTRY
KG
~ _
10.5
SOCKET MOUNT
165 165
dia.
dia.
CABLE ENTRY
IP65
IP66
BOLLARD
PACKING
BALLAST
GROUND LEVEL
CABLE ENTRY
IP67
IP68
IP40
III
IP54
D
1133
IK10
IP56
165
dia.
GROUND
LEVEL
LEVEL
BASE
NOTES
The information provided within the above table is for reference only.
The values shown above are not based on specific soil or environmental conditions.
Planting information for sockets is to be taken from guidance provided by NAL Ltd.
Y X
Z
PN 3440A Sep 21
