Assembly
A: Floater
B: Upper cover
B-1: Jet head
C: Filter
D: Bottom base
E: Charger
There is a rotation jet head at the upper cover, the water is
passing from bottom to the jet head to make the robot
moving. While facing obstacle, the jet head turns around 180
degrees, the robot rounds the obstacle and moving by another
line. The rubbish is collected and installed by the bottom filter
cabine.

Assembly and operation

Charging warning
Use only the original external adapter and the charging cable
provided.
Make sure the robot and charger ports are clean and dry
before installation.
Power up the robot before using it for the first time (about 4-5
hours)
Note:
Once the robot starts charging, the
indicator light on the external adapter
will turn red. When the robot is fully
charged, the indicator light will turn
green.
3
A
E
B
C
D
Switch
Charging port
3
B-1
Bottom cover body assembly bottom
