COMPONENTS:
A. FOLDING BUTTON
B. FOOTREST ADJUSTMENT BUTTON
C. ARMREST REMOVAL BUTTON
D. FRONT WHEEL X2
E. FRONT WHEEL STEERING LOCK BUTTON
F. REAR WHEEL X2
PRODUCT ASSEMBLY:
1. Grab the handle and pull it upwards to unfold the frame.
2. Install the rear wheels by inserting them into the holes on the rear axle until you hear a click, then
you are sure that the wheels are properly and securely assembed. To remove the rear wheels, pull
the lock button located on the bottom of the brake axle and pull the wheels out of the holes.
3. The front wheels have a quick release function, take the wheel and point the protruding spike
towards the hole on the front of the cart. Place the skewer in the hole and press down. Pull down
and side to side to make sure the wheel is properly locked. Repeat the same operation for the other
front wheel (fig. 4). To remove the front wheels, press the button located on the side of the wheel.
A button located at the front of the front wheels allows you to lock the wheels from turning. To block
manoeuvring, drag the slider down.
PRODUCT FUNCTIONS:
• This stroller is equipped with a foot parking brake on the rear axle. Press the brake pedal downwards
so that the brake is activated. Unlocking takes place after lifting the pedal up.
• To adjust the backrest to a sitting position, squeeze the button on the back of the backrest and slide
it up towards the backrest. To adjust the backrest to a lying position, squeeze the adjustment button
and pull it downwards against the backrest.
• To adjust the footrest, press both the adjustment buttons on both sides of the footrest.
• To fold the hood, grasp the front of the hood and push it towards the push handle. In order to unfold
the canopy, do the opposite, pull the edge of the canopy in the direction opposite to the handle.
SEAT BELTS:
• To fasten the seatbelts put both shoulder buckles on top of the side belt buckle and then place
combined shoulder and side straps in the crotch belt buckle.
• To unfasten the seat belts press the central button and unbuckle all the clasps.
• The straps can be adjusted to fit the child properly, but be careful that the child is not too tightly
compressed and can breathe freely. When fastening the seatbelts, make sure that the child's hands
are not near the buckle.
• If the stroller is intended for a small child, adjust the belts as shown in Fig. 16. The belt should be
passed through the loop on the backrest. To remove the belt from the belt loop, remove the textile
cover from the shoulder belt and then pass the belt through the belt loop. After re-attaching the
textile cover, the belts can be used for a larger child. The belts should be at the height of the child's
shoulders.
EN
G. FRONT WHEEL REMOVAL BUTTON
H. REAR WHEEL REMOVAL BUTTON
I. REAR WHEELS BRAKE
J. ACCESSORIES: BACKPACK, CUP HOLDER,
MOSQUITO NET, RAIN COVER
