ECX RC-SXE Kurzanleitung Seite 2

Functions:
• Controlling audio streaming playback
• Preset selection
• Input source selection
• Source selection for the automatic
crossfading
• Control of the main volume
• Subwoofer level control
CAUTION: The DSP control via RC-SXE controller and PC software or via smartphone app does not work at the same time.
Use only one of the three control options.
In the main menu, the main volume
can be adjusted using the rotary knob.
Controller range = - 40 to 6.
NOTE: After about 5 seconds of inac-
tivity, the display always switches back
to the main menu.
In the main menu, briefly press the ro-
tary knob 2 x to display the SOURCE
menu. The desired input source can
then be selected using the rotary knob
and confirmed by pressing the rotary
knob.
DECLARATION OF CONFORMITY
Audio Design GmbH hereby declares that ESX RC-SXE complies with Directive 2014/53/EU. The full declaration of confor-
mity can be viewed at www.esxaudio.de/ce
ESX CAR AUDIO SYSTEMS · AM BREILINGSWEG 3 · D-76709 KRONAU · WWW.ESXAUDIO.DE
RC-SXE
D S P C O N T R O L
Scope of delivery:
1 x DSP Remote Controller
1 x Die-Cast installation housing
4 x Mounting screws
1 x Adhesive pad
1 x 5m extension cable
In the main menu, briefly press the ro-
tary knob 1 x to display the SUB menu.
The subwoofer level can then be ad-
justed using the rotary knob. Controller
range = - 40 to 6.
In the main menu, briefly press the
rotary knob 3 x to display the MIX
SOURCE menu. The source for the
automatic crossfade can then be
selected using the rotary knob and
confirmed by pressing the rotary knob.
Specifications:
Bluetooth Version 5.0
Frequency range 2.400 - 2.484 MHz
Max. emitted power 30,0 dBm
In the main menu, briefly press the
rotary knob 4 x to display the MEMO-
RY menu. The desired preset can then
be selected using the rotary knob and
confirmed by pressing the rotary knob.
The playback of the audio streaming
can be controlled using the three hard-
ware buttons next to the display.
