Party Light & Sound PARTY-SINGTOGETHER Bedienungsanleitung Seite 4

USE WITH A TF CARD
Connect your TF card to the SD input (13). The speaker will automatically select the SD input. Select a file via
the backward (15) or forward (17) buttons. Press the PLAY/PAUSE button (16) to start playing the file.
USE WITH A USB STICK
Connect your USB stick to the USB input (14). The speaker will automatically select the USB input. Select a file
via the backward (15) or forward (17) buttons. Press the PLAY/PAUSE button (16) to start playing the file.
Please note: If both inputs, SD and USB, are connected, the player will select automatically the latest connected input source.
BLUETOOTH PAIRING
1. Power the speaker ON. A tone will be heard and the LED indicator will quickly flash BLUE.
2. Enable the Bluetooth search function on your mobile device. Select "PARTY-SINGTOGETHER" in the list of
found devices.
3. After successful pairing, a tone will be heard and the LED indicator will slowly flash BLUE.
USE WITH WIRED DEVICE
Insert one connector of a 3.5 mm auxiliary cable into the 3.5mm auxiliary input port on the top of the speaker.
Insert the other connector into the headphone jack of your media-playing device. The LED indicator will light
BLUE when an AUX cable is connected.
ALL BLUETOOTH PAIRINGS WILL BE DISCONNECTED WHILE THE 3.5MM AUX JACK IS CONNECTED.
OPERATION OF THE LED LIGHT EFFECT
Press the [LED] button to cycle through the light modes.
SPECIFICATIONS
Input voltage
USB output voltage
Built-in battery
Play time at average volume
Signal-to-noise ratio
Frequency response
BT frequency
Bluetooth version
Bluetooth mode
Max. RF transmission power
Dimensions
Height of the stand
Weight
4
5V�� 1A via supplied USB charging lead
5V�� 0.5A
Lithium 3.7V�� 1500mAh
>65dB
80Hz - 18kHz
2402-2480MHz
HSP, HFP, A2D
5.75dBm
195 x 208 x 213mm
35-157cm
Code: 10-9031PLS
PARTY-SINGTOGETHER
2 hours
5.0
2.08kg
