Operating Instructions
USB-C®/USB-A Audio Adapter
Item no: 2375177
1 Operating Instructions for download
Use the link
www.conrad.com/downloads
operating instructions (or new/current versions if available). Follow the instructions on the web page.
2 Intended use
The product is a USB to audio adapter. The product functions as an external sound card.
Connect an audio source (example: notebook) to the adapter via the USB cable and stream audio to
the TRRS jacks.
If the audio source supports USB-C® PD, you can connect a USB-C® PD power source to the USB-
C® PD input port to charge/power the connected audio source (example: notebook).
The product is intended for indoor use only. Do not use it outdoors.
Contact with moisture must be avoided under all circumstances.
If you use the product for purposes other than those described, the product may be damaged.
Improper use can result in short circuits, fires, or other hazards.
The product complies with the statutory national and European requirements.
For safety and approval purposes, you must not rebuild and/or modify the product.
Read the operating instructions carefully and store them in a safe place. Make this product available to
third parties only together with the operating instructions.
All company names and product names are trademarks of their respective owners. All rights reserved.
USB4®, USB Type-C® and USB-C® are registered trademarks of USB Implementers Forum.
3 Delivery contents
■
Product
4 Description of symbols
The following symbols are on the product/appliance or are used in the text:
The symbol warns of hazards that can lead to personal injury.
This product must only be used in dry, enclosed indoor areas. It must not become damp or
wet.
5 Safety instructions
Read the operating instructions carefully and especially observe the safety informa-
tion. If you do not follow the safety instructions and information on proper handling,
we assume no liability for any resulting personal injury or damage to property. Such
cases will invalidate the warranty/guarantee.
5.1 General
■
The product is not a toy. Keep it out of the reach of children and pets.
■
Do not leave packaging material lying around carelessly. This may become dangerous playing ma-
terial for children.
■
If you have questions which remain unanswered by this information product, contact our technical
support service or other technical personnel.
■
Maintenance, modifications and repairs must only be completed by a technician or an authorised
repair centre.
5.2 Handling
■
Handle the product carefully. Jolts, impacts or a fall even from a low height can damage the
product.
5.3 Operating environment
■
Do not place the product under any mechanical stress.
■
Protect the appliance from extreme temperatures, strong jolts, flammable gases, steam and
solvents.
■
Protect the product from high humidity and moisture.
■
Protect the product from direct sunlight.
5.4 Operation
■
Consult an expert when in doubt about the operation, safety or connection of the product.
■
If it is no longer possible to operate the product safely, take it out of operation and protect it from
any accidental use. DO NOT attempt to repair the product yourself. Safe operation can no longer
be guaranteed if the product:
– is visibly damaged,
– is no longer working properly,
– has been stored for extended periods in poor ambient conditions or
– has been subjected to any serious transport-related stresses.
5.5 Connected devices
■
Also observe the safety and operating instructions of any other devices which are connected to the
product.
6 Cleaning and care
Important:
– Do not use aggressive cleaning agents, rubbing alcohol or other chemical solutions. They dam-
age the housing and can cause the product to malfunction.
– Do not immerse the product in water.
1. Disconnect the product from the power supply.
2
(alternatively scan the QR code) to download the complete
■
Operating instructions
2. Clean the product with a dry, fibre-free cloth.
7 Disposal
This symbol must appear on any electrical and electronic equipment placed on the EU
market. This symbol indicates that this device should not be disposed of as unsorted muni-
cipal waste at the end of its service life.
Owners of WEEE (Waste from Electrical and Electronic Equipment) shall dispose of it sep-
arately from unsorted municipal waste. Spent batteries and accumulators, which are not
enclosed by the WEEE, as well as lamps that can be removed from the WEEE in a non-de-
structive manner, must be removed by end users from the WEEE in a non-destructive
manner before it is handed over to a collection point.
Distributors of electrical and electronic equipment are legally obliged to provide free take-back of
waste. Conrad provides the following return options free of charge (more details on our website):
■
in our Conrad offices
■
at the Conrad collection points
■
at the collection points of public waste management authorities or the collection points set up by
manufacturers or distributors within the meaning of the ElektroG
End users are responsible for deleting personal data from the WEEE to be disposed of.
It should be noted that different obligations about the return or recycling of WEEE may apply in coun-
tries outside of Germany.
8 Technical data
Input ..................................................... USB-C®/USB-A cable:
Output.................................................... USB-C® cable (via USB-C® plug):
Audio ports ............................................ 2x 3.5 mm TRRS jacks
Operating system support ..................... Windows® 7 and higher
Operating temperature ......................... 0 to +40 °C
Operating humidity ............................... 20 - 80 % RH (non-condensing)
Storage temperature ............................. 0 to +40 °C
Storage humidity ................................... 20 - 80 % RH (non-condensing)
Dimensions (W x H x D) ....................... 43 x 10 x 28 mm
Weight (approx.) ................................... 22 g
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method (e.g. photocopying, microfilming or the capture in
electronic data processing systems) requires prior written approval from the editor. Reprinting, also in part, is prohibited.
This publication reflects the technical status at the time of printing.
Copyright by Conrad Electronic SE.
*2375177_V1_1024_dm_mh_en 1657650059-2 I1/O1 en
5 V/DC, max. 1000 mA
USB-C® PD input port:
5 V/DC, 3 A; 9 V/DC, 3 A; 12 V/DC, 3 A;
15 V/DC, 3 A; 20 V/DC, 5 A; max. 100 W
5 V/DC, 3 A; 9 V/DC, 3 A; 12 V/DC, 3 A;
15 V/DC, 3 A; 20 V/DC, 5 A; < 100 W
Simultaneous use is supported
macOS 10.5 and higher
