9 Installation and Connection

Connection to Component Output

- Connect the MviX media player to your TV
using a component cable as shown in the
image above.
- Turn on the MviX and TV.
- Select appropriate video input mode on your
TV (in this case, Component input mode)
(cable not supplied).
- Component connection is commonly used on
most HDTV's, DLP-TVs, Plasma TVs etc.
Unicorn Information System
White, Red Cable
Green, Blue, Red Cable
20
Connection to 2-CH (RCA) of
normal TV
- Connect left (white), right (red) sound
output to the appropriate terminal of your
TV or Hi-Fi Device using the 2-CH RCA
cable (cable supplied).
