Oakcastle PS500 Benutzerhandbuch Seite 5

Back View & Control Panel
1. Power ON/OFF, Volume +/-
2. USB Type-C Charging Port (DC5V)​
3. Mode & Lighting Modes​
4. Next /Forward ​
5. Play, Pause/TWS ​
6. Previous​
7. LCD Display Screen ​
8. Charging LED Light​
9. Echo +/-
10. Microphone Volume +/-
11. Treble +/-*​
Controls & Functions
1 2 3 4 5 6
13 14 15 16
8
7
11 12
9 10
12. Bass +/-
13. Wired Microphone Port ​
14. AUX-In Port ​
15. USB Playback Port ​
16. SD (TF) Card Slot ​
17. Tripod Stand hole and screw ​
Please note: To change the lighting modes,
you must press and hold for 2-3 seconds
the Mode/ Lightning button (Ref.3).
EN
17
5
