USER MANUAL
InLine® Charging Cube, 3x protective contact with shutter,
2x USB-C, 2x USB-A, with power-switch, 2 m
GENERAL INFORMATION
Validity:
This user manual applies to the following product:
• 16499A / 16499B InLine® Charging Cube, 3x protective contact with shutter,
2x USB-C, 2x USB-A, with power-switch, 2 m
Manufacturer:
INTOS ELECTRONIC AG
Siemensstraße 11
D-35394 Gießen
service@inline-info.com
Date: August 2023
CONTENT OF DELIVERY
1x Charging Cube, 3x protective contact with shutter, 2x USB-C, 2x USB-A,
with power-switch, 2 m
1x Operating instructions
Please check the content of delivery for completeness. If individual components
are missing, please contact your dealer.
EXPLANATION OF WARNING SYMBOLS AN NOTES
This symbol indicates information that contributes to a better unders-
tanding.
Use the device inside only
INTENDED USE
The InLine® Charging Cube is used to connect up to three electrical consumers,
2 USB-A and 2 USB-C sockets are also available. Use the power strip only in dry,
closed rooms and do not expose it to direct sunlight, extreme temperatures or
humidity.
IMPROPER USE
As improper use within the meaning of foreseeable misuse obtains:
• Do not disassemble the InLine® power strip, 3x protective contact, with Quick
Charge USB.
• Never use the power strip with a generator, life support device, other medical
device, car battery charger, heater or sump pump.
• Never connect power strips in series
• Do not cover the power strip during use
USE
• Plug the power cord into a free power outlet
• Connect devices to be operated and / or charged via USB as needed.
Check the power strip before use for possible damage such as
cracks in the housing. If any damage is obvious, do not use the power
strip anymore!
• The power strip is intended only for the connection of 250 V devices.
• Use only in closed and dry rooms.
• The total power of the connected electrical equipment must not exceed the
rated power of up to 3680 watts of this product.
• The power strip should only be connected to a grounded power outlet.
• The power strip is only power-free when the plug is pulled.
SPECIFICATION
• Input voltage: AC 250V
• Current: 16.0A
• Connected load: max. 3680 W
• Total USB power: 5.0 V DC, 3.4 A total, maximum 17.0 W
• Connections : 3x protective contact with shutter, 2x USB-C, 2x USB-A
• Cable: H05VV-F3G1,5 mm²
• Average active effi ciency: 86,26%
• Effi ciency at light load (10%): 81,04%
• No-load power consumption: 0,09 W
• Length: 2 m
• Operating display: Button LED lights up red
• Cube dimensions: 80 x 80 x 85 mm (L x W x H)
• Weight: 410 g
• Color : white or black
MAINTENANCE AND CLEANING
• Clean the power strip with a dry and lint-free cloth when it is not connected to
the mains.
• Do not use cleaning agent.
SIMPLIFIED EC DECLARATION
OF CONFORMITY
The Manufacturer / Importer:
INTOS ELECTRONIC AG
Siemensstrasse 11
35394 Giessen
hereby declares that the InLine®
provisions of the EMC (2014/30/EU), Low Voltage (2014/35/EU), RoHS (2011/65/EU
+ 2015/863/EU) directives and the regulation laying down ecodesign requirements
for external power supplies (2019/1782/EU).
The full part of the EU Declaration of Conformity is available at the
following web address:
https://www.inline-info.com/en/downloadcenter
DISPOSAL
Electrical and electronic devices as well as batteries must not be disposed
of with household waste. The consumer is legally obliged to return electrical
and electronic equipment and batteries at the end of their service life to the public
collection points set up for this purpose or to the point of sale.
DISCLAIMER
2nd edition English 31/2023
Documentation © 2023 INTOS ELECTRONIC AG
All rights reserved. No part of this manual may be reproduced in any form or by any
means, electronic, mechanical or chemical, without the prior written permission of
the publisher.
It is possible that this manual may still contain typographical defects or misprints.
However, the information in this manual will be checked regularly and corrections
will be made in the next edition. We accept no liability for errors of a technical
or printing nature and their consequences. All trademarks and industrial property
rights are acknowledged. Changes in the sense of technical progress can be made
without prior notice. Our products, including packaging, are not toys, they may
contain small parts and sharp objects.
Please Keep away from children.
Owner of the Trademark:
Charging Cube complies with all
