Technical data
Parameter description
Product name
Model
Voltage [V~]
Frequency [Hz]
Power [W]
Protection class
Dimensions [Width x Depth x Height; mm]
Weight [kg]
Temperature range [ o C]
Timer range [min]
Purpose
Ionic Standing Hair Dryer is a professional-grade hair drying tool designed to deliver quick and
efficient drying while minimizing damage and frizz.
Installation
1. Remove all components from the box as per (Figure 1).
2. Connect the Lower Pole to the Center Hub. Place the Center Hub on the flow or flat surface
and push down firmly while until it reaches the bottom of the Hub. (Figure 2)
3. Turn the Center Hub with Lower Pole over and begin connecting each of the 5 legs to the
Hub making sure they are pushed in as far as possible. (Figure 3)
4. Place the plastic clamp and metal plate over the recessed middle area of the Center Hub
and tighten into place using the "L" shaped bolt manually, so the Legs, Center Hub and
Lower Pole are all secured together. (Figure 4 and Figure 5)
5. Insert the wheels into the base. (Figure 6)
6. Connect the Lower Pole and Upper Pole with the connection tube, push firmly until the poles
reaches the middle of the connection tube, then fasten both screws on the connection tube
with the L-shape tool, so that the Upper Pole, Lower Pole and the connection tube are all
secured together. (Figure 7)
EN
Parameter value
Ionic standing hair dryer
PHY-HD_01
230 / 50
1000
670 x 670 x 1770
7.6
0-70
0-60
PHY-HD_02
50
II
