INSTRUCTION MANUAL
GENERAL INFORMATION
Validity:
These operating manual applies to the following products:
• 60647 InLine® USB 2.0 Switch manual, USB-A device to 2 PC
• 60648 InLine® USB 2.0 Switch manual, USB-A device to 4 PC
• 60606A InLine® RJ45 switch manual, 1 to 2, 3x RJ45 jack
• 60606B InLine® RJ45 switch manual, 1 to 4, 5x RJ45 jack
• 60609 InLine® Serial switch manual 2-port, RS232, 9-pin
• 60610 InLine® Serial switch manual 4-port, RS232, 9-pin
• 60608 InLine® VGA switch manual 2-port, 15-pin HD
• 89302I InLine® AV switch manual 2-port, 3x Cinch IN/OUT
• 89304I InLine® AV switch manual 4-port, 3x Cinch IN/OUT
Manufacturer:
INTOS ELECTRONIC AG
Siemensstraße 11
D-35394 Gießen
service@inline-info.com
Date: March 2024
CONTENT OF DELIVERY
• 1x InLine® manual switch
• 1x Instruction manual (German/English)
Check the contents of delivery for completeness. If individual components are mis-
sing, please contact your specialist dealer.
INTENDED USE
The manual switch offers the simple and fast possibility of switching data or AV
signals via 2 or 4 ways. Switching is done via front keys on the housing and is purely
mechanical, the connections are connected 1:1.
General warnings
• Do not expose the InLine® switch to excessive heat.
• Protect from dust and moisture.
NON-INTENDED USE
The following is considered improper use in the sense of foreseeable misuse:
• Do not use the InLine® manual switch outdoors.
• Do not disassemble the InLine® manual switch.
TECHNICAL FEATURES
• Simple manual data switch, 2-fold or 4-fold
• Purely mechanical switching of signals
• No electronic components in the switch
• Bi-directional use possible (1 input to 2/4 outputs or 2/4 inputs to 1 output)
• Full 1:1 assignment of all connections
• Simple metal housing with 2/4 front buttons for port selection
MAINTENANCE AND CLEANING
• Clean the InLine® manual switch with a dry, velvety cloth.
• Do not use water or other cleaning liquids that could damage the electronics.
DISPOSAL
Electrical and electronic equipment and batteries must not be disposed of
with household waste. The consumer is legally obliged to return electrical
and electronic equipment and batteries at the end of their service life to the desig-
nated public collection points or to the point of sale.
2
SIMPLIFIED EC DECLARATION
OF CONFORMITY
The Manufacturer / Importer:
INTOS ELECTRONIC AG
Siemensstrasse 11
35394 Giessen
hereby declares that this InLine® manual switch complies with all relevant provisi-
ons of the ROHS (2011/65/EU + 2015/863/EU) directives.
The complete part of the EU Declaration of Conformity is available at
the following internet address:
https://www.inline-info.com/en/downloadcenter
DISCLAIMER
2nd edition English 12/2024
Documentation © 2024 INTOS ELECTRONIC AG
All rights reserved. No part of this manual may be reproduced in any form or du-
plicated or processed using electronic, mechanical or chemical processes without
the written consent of the publisher. It is possible that this manual may still contain
typographical errors or misprints. However, the information in this manual is che-
cked regularly and corrections are made in the next edition. We accept no liability
for technical or printing errors and their consequences. All trademarks and indust-
rial property rights are recognised. Changes in the sense of technical progress can
be made without prior notice. Our products, including the packaging, are not toys
and may contain small parts and sharp objects.
Please keep away from children.
