ENGLISH
Changing the channel setting
The telephone transmitter sends signals wirelessly to the receiver installed in the
Lynx system. It can transmit on a total of 15 different channels: 1-9, A-F.
Channel 0 is reserved for a common fire alarm and should not be used.
Transmitters and receivers in the system must be set to the same channel so that
they can communicate. They are all pre-set to channel 9, and then
operate together without alteration.
In some cases, it may be necessary to change the channel setting. If two or more
users live near one another, the alarms can interfere. This can be rectified by
changing the channel settings so that they are different for everyone. Any channel
can be selected except Channel 0.
If you need to change channels on the receiver, see the receiver user manual. If
you need to change the channel on the telephone transmitter, proceed as follows:
The channel selector is on the rear. Use a
small screwdriver and turn the yellow arrow
towards the required channel.

Technical data

Modulation:
Frequency:
Power supply:
Service life:
Range:
Channels:
Connection:
Dimensions:
Weight:
Any issues relating to the EU Medical Device Directive
93/42/EEC should be directed to AB Transistor Sweden.
6
AM.
433,92 MHz.
3 V lithium battery (CR 2032). WARNING:
Risk of explosion if fitted incorrectly!
5 years (with 3 alarms per day). Maximum 70,000 alarms.
Up to 30 m indoors.
16.
Modular switch for adapter plug.
60 x 40 x 23 mm.
35 g.
