Sungrow iHomeManager Kurzanleitung Seite 9

1.3Retrofitsystemwiththird-partyinverter(WiNet)
Third-party inverter
PV
PV
Inverter 1
·
SBR/SBH ·
·
PV
Inverter n
n ≤ 5
SBR/SBH
Inverter
SH5.0~10RT-20
SH5~25T
1.4Retrofitsystemwiththird-partyinverter(RS485)
Third-party inverter
PV
PV
Inverter 1
·
SBR/SBH
·
·
PV
Inverter n
n ≤ 5
SBR/SBH
Inverter
SH5.0~10RT-20
SH5~25T
PROD.CT
iHomeManager
Battery RACK
SBR096-256
SBH100-400
PROD.CT
iHomeManager
Battery RACK
SBR096-256
SBH100-400
8
Heat Pump
Home Load
EV Charger
Router
Heat Pump
Home Load
EV Charger
Router
GRID.CT
Grid
iSolarCloud
EV Charger
AC11E-01
AC22E-01
GRID.CT
Grid
iSolarCloud
EV Charger
AC11E-01
AC22E-01
AC
DC
CT signal line
DO
ETH
WLAN
user
AC
DC
CT signal line
DO
RS485
ETH
WLAN
user
