USER MANUAL
InLine® USB Charger Single USB-C, Power Delivery, PPS, 33W
GENERAL INFORMATION
Validity:
This user manual applies to the following product:
• 31501B InLine® USB Charger Single USB-C, Power Delivery, PPS, 33W, black
• 31501C InLine® USB Charger Single USB-C, Power Delivery, PPS, 33W, white
Manufacturer:
INTOS ELECTRONIC AG
Siemensstraße 11
D-35394 Gießen
Date: November 2023
CONTENT OF DELIVERY
1x InLine® USB Charger Single USB-C, Power Delivery, PPS, 33W
1x Instruction manual
Please check the content of delivery for completeness. If individual components
are missing, please contact your dealer.
EXPLANATION OF WARNING SYMBOLS AN NOTES
This symbol indicates information that contributes to a better unders-
tanding.
This symbol indicates that there are fundamental risks to the health of
persons.
INTENDED USE
The InLine® USB power supply is a fast charger for compatible USB devices. Con-
ventional end devices can also be charged with this power supply, but take longer
to fully recharge.
NOT INTENDED USE
Not intended use in the sense of a foreseeable misuse shall be deemed to be im-
proper use:
• Do not disassemble the InLine® USB power supply unit.
• Only use the power supply in dry, closed rooms and do not expose it to direct
sunlight, extreme temperatures or humidity.
Before use, check the power supply unit for possible damage such as
cracks in the housing. If damage is obvious, do not use the power supply
again!
If you notice any damage to the device, do not use the device! There may
be a risk of electric shock if you continue to use the unit.
TECHNICAL FEATURES
• USB power supply / charger
• USB-C output:
• (PD3.0) DC 5.0 V / 3.0 A - 9.0 V / 3.0 A - 12.0 V / 2.5 A - 15.0 V / 2.0 A -
20.0 V / 1.5 A (max. 30,0 W)
• (PPS) DC 3.3-11.0 V / 3.0 A - 3.3-16.0 V / 2.0 A (max. 33,0 W)
• Input voltage: 100-240VAC, 50/60Hz
• Surge and short circuit protection
• If the temperature of the power supply unit is too high, it switches off automati-
cally and continues charging after cooling down
• Dimensions: 70x31x31 mm (LxHxW)
• Weight: approx. 51 g
• Average active effi ciency: 85.11 % (230 V, 50 Hz, 5.0 V, 3.0 A),
90,95 % (230 V, 50 Hz, 20.0 V, 1.5 A)
• Effi ciency at low load (10 %): 82.22 % (230 V, 50 Hz, 5.0 V, 3.0 A),
84.31 % (230 V, 50 Hz, 20.0 V, 1.5 A)
• No-load power consumption: 0,05 W (230 V, 50 Hz, 5.0 V, 3.0 A),
0.06 W (230 V, 50 Hz, 20.0 V, 1.5 A)
SYMBOLS
Class II equipment, IEC 60417-5172 (2003-02)
Use the device inside only
The power adapter complies with effi ciency level VI according to the
Ecodesign Regulation (EU) No 2019/1782.
SIMPLIFIED EC DECLARATION
OF CONFORMITY
The Manufacturer / Importer:
INTOS ELECTRONIC AG
Siemensstrasse 11
hereby declares that the InLine® USB power adapter complies with all relevant
provisions of directives LVD (2014/35/EU), EMC (2014/30/EU), RoHS (2011/65/EU +
2015/863/EU) and regulation of ecodesign requirements for external
power supplies (2019/1782/EU).
The full part of the EU Declaration of Conformity is available at the
following web address:
https://www.inline-info.com/en/downloadcenter
APPLICATION
• Plug the power supply unit into a free socket.
• If necessary, connect the device to be charged.
MAINTENANCE AND CLEANING
• Clean the power supply unit with a dry, velvety cloth.
• Do not use cleaning chemicals.
DISPOSAL
Electrical and electronic devices as well as batteries must not be disposed
of with household waste. The consumer is legally obliged to return electrical
and electronic equipment and batteries at the end of their service life to the public
collection points set up for this purpose or to the point of sale.
DISCLAIMER
1st edition English 45/2023
Documentation © 2023 INTOS ELECTRONIC AG
All rights reserved. No part of this manual may be reproduced in any form or by any
means, electronic, mechanical or chemical, without the prior written permission of
the publisher.
It is possible that this manual may still contain typographical defects or misprints.
However, the information in this manual will be checked regularly and corrections
will be made in the next edition. We accept no liability for errors of a technical
or printing nature and their consequences. All trademarks and industrial property
rights are acknowledged. Changes in the sense of technical progress can be made
without prior notice. Our products, including packaging, are not toys, they may
contain small parts and sharp objects.
Please Keep away from children.
