Item Parameters
3 Time-Delay
setting when
reaching the
Max. pressure
4 Load for 3
seconds to
store
setting
value
" "
Item Parameters
1 Switch the
display
working
pressure unit
2
Detection time
setting of water
shortage
3 LCD screen
display
''loAd'' or
''- - - -'' for
3 seconds
to store
and finish
the setting
kinpumps.com
Display Default Data
Code Unit range
Delay Sec 0 – 60
loAd - -
Display Default Data
Code Unit range
Unit - -
P-Dry sec 1 - 120
P-Dry kg/cm² 0.01 - 10.00
Description
a. Select to modify the Time-delay setting when reaching the Max.
pressure, press the left or right button to adjust the value, after
finishing the setting, press the SET button and go to ''loAd''
display.
b. Stay on this screen for 30 seconds, the display screen will back
to the actual pressure conditions automatically and the preset
data value is not stored.
c. Choose not to modify the delay time, press the SET button, and
LCD display ''loAd''.
Above setting value are stored and 3 seconds later, go to the actual
pressure value display automatically.
Description
A. Select to switch the Unit of working pressure, press the right
button to change the pressure unit (cycle: kg/cm² · Psi · bar·
kg/cm²), then press the SET button once and go to next
parameter setting.
B. Stay on this screen for 30 seconds, the display screen will back
to the actual pressure conditions automatically and the preset
data value is not stored.
C. Choorse not to modify the working pressure unit, press the set
button once, and go to next parameter setting.
Select to modify the detection time after reaching the pressure
A.
setting of water shortage (dry running), press the left or right
button to adjust the value, after finishing the setting, press the
SET button and go to next parameter setting.
Stay on this screen for 30 seconds, the display screen will back
B.
to the actual pressure conditions automatically and the preset
data value is not stored.
Choose not to modify P-Dry detection time setting, press the
C.
SET button once, and go to next parameter setting.
A. Select to modify the pressure of water shortage, press the left
or right button to adjust the value, after finishing the setting,
press the SET button and go to next parameter setting.
B. Stay on this screen for 30 seconds, the display screen will back
to the actual pressure conditions automatically and the preset
data value is not stored.
C. Choorse not to modify the pressure of water shortage, press
the SET button, and go to next parameter setting.
