Goobay 74385 Betriebsanleitung Seite 2

EN User Manual
USB-C 3.1 to RJ45 Ethernet Cable, Slim
TM
1 Safety Instructions
The user manual is part of the product and contains important information for correct use.
• Read the user manual completely and carefully before use.
The user manual must be available for uncertainties and passing the product.
• Keep this user manual.
• Do not modify product and accessories.
• Use product, product parts and accessories only in perfect condition.
• Avoid stresses such as heat and cold, moisture and direct sunlight, microwaves,
vibrations and mechanical pressure.
• In case of questions, defects, mechanical damage, trouble and other problems,
non-recoverable by the documentation, contact your dealer or producer.
Risk of injury by stumbling and falling.
• Install the product and the devices attached to it in such a way that no persons or
property can be injured or damaged, e.g. by falling, tripping or similar.
Not meant for children. The product is not a toy!
• Secure packaging, small parts and insulation against accidental use.
• Do not turn or bend the product when it is plugged in or put any other mechanical
load on it.
2 Description and Function
2.1 Product
The Ethernet cable enables a stable, wired Internet connection to USB-C
without a separate network connection.
○ fast connection from a computer to a cabled network
○ suitable for computers and smart devices with USB-C
2.2 Scope of Delivery
USB-C 3.1 to RJ45 Ethernet Cable, Slim, User Manual
TM
2.3 Operating Elements
1 USB-C
3.1 plug
TM
2.4 Specifications
Art. Number
Connection 1
Connection 2
Data transmis-
sion rate
Material
contacts
Material
jacket/housing
Material
cable sheath
Cable
Weight (g) 32.2 40.1
Cable length (m) 1 1.5
3 Intended Use
This product is intended exclusively for private use and its intended purpose.
This product is not intended for commercial use. We do not permit using the
device in other ways like described in chapter "Description and Function" or in
the "Safety Instructions". Use the product only in dry interior rooms. Not
attending to these regulations and safety instructions might cause fatal accidents,
injuries, and damages to persons and property.
4 Preparation
1. Check the scope of delivery for completeness and integrity.
2. Compare the specifications of all used devices and ensure compatibility.
5 Connection and Operation
5.1 Connection
1. Plug the RJ45 plug (2) of the Ethernet cable into a network device (e.g. HUB,
router, switch).
2. Insert the USB-C plug (1) of the cable into a USB-C
TM
PC.
5.2 Installation and Settings for Windows
This product does not require any driver for installation. Installation will start
automatically when connecting the adapter with the computer.
The device is displayed in ʺDevice Managerʺ once the installation is completed.
REV2024-06-03
V1.0alw
Subject to change without notice.
ports
TM
2 RJ45 plug
RJ45 plug (8P8C)
USB-C 3.1 plug
TM
1 Gbit/s
nickel-plated
PVC/PE
cotton
CAT 6
48 63.8 95.4 134.9 174.4
2 3 5 7.5
port on your notebook/
TM
74377, 74378, 74379, 74380, 74381, 74382, 74383, 74384
74393, 74394, 74395, 74396, 74397, 74398, 74399, 74400
5.2.1 Automatic Setting of the IP Address
1. After installation, click on ʺSettings / Network & Internet / Network and Sharing
Centerʺ to display the new Internet connection.
When the network has received the IP address, you can connect to the network.
5.2.2 Manual Setting of the IP Address
1. Click on the new Internet connection.
A new window opens.
2. Click on ʺPropertiesʺ.
3. Click on ʺInternet Protocol Version 4 (TCP/IPv4)ʺ.
4. Select ʺUse the following IP addressʺ and enter the IP address.
5. Select ʺUse the following DNS server addressʺ and enter the DNS address.
5.3 Installation and Settings for MAC OS
This product has a Plug & Play connection on MAC OS.
5.3.1 Automatic Setting of the IP Address
When the network adapter has been connected and detected, it appears under
ʺSystem Preference / Networkʺ.
5.3.2 Manual Setting of the IP Address
1. Select the network adapter in the menu ʺNetworkʺ.
2. Click on ʺAdvancedʺ.
devices
TM
3. Click on ʺTCP/IPʺ.
4. Select ʺUsing DHCP with manual addressʺ in the ʺConfigure IPv4ʺ box and
enter the IP address.
6 Maintenance, Care, Storage and Transportation
The product is maintenance-free.
NOTICE!
• Only use a dry and soft cloth for cleaning.
• Do not use detergents or chemicals.
• Store the product out the reach of children and in a dry and dust-protected
ambience when not in use.
• Store cool and dry.
• Keep and use the original packaging for transport.
7 Disposal Instructions
7.1 Product
According to the European WEEE directive, electrical and electronic equipment
must not be disposed with consumers waste. Its components must be recycled or
disposed apart from each other. Otherwise contaminative and hazardous
substances can damage the health and pollute the environment.
As a consumer, you are committed by law to dispose electrical and electronic devices to
the producer, the dealer, or public collecting points at the end of the devices lifetime for
free. Particulars are regulated in national right. The symbol on the product, in the user
manual, or at the packaging alludes to these terms. With this kind of waste separation,
application, and waste disposal of used devices you achieve an important share to
environmental protection.
WEEE No: 82898622
7.2 Packaging
Packaging can be disposed of free of charge at the suitable collection points – pa-
per belongs in paper bins, plastics belong in yellow sacks and glass belongs in
used glass bins.
DE4535302615620
