STOREMIC SMFS02B Bedienungsanleitung Seite 7

For Wood Stud/Für Holzständer/Pour les montants en bois/
1A
Para vigas de madera/Per montanti in legno
X X
WARNING:
For wood stud mounting, wall
anchors [F] and [G] are not
F G
necessary.
For Drywall/Für Trockenbauwände/Pour les cloisons sèches/
1B
Para paredes de yeso/Per cartongesso
[Not Included] [Optional]
1 21/32 in.(42mm)
ø5/64 in.(ø2mm)
For Long Lag Screw For Long Lag Screw
The wall anchor [F] The wall anchor [F]
is for drywall only! is for drywall only!
Note: Please keep 5/16 in.(8mm)
spacing left for the screws [D] and [E].
Note: Please keep 5/16 in.(8mm)
spacing left for the screws [E].
F
06
E
F
5/16 in.(8mm)
D/E
5/16 in.(8mm)
E
F
D
E
