3. Calibration and device setup
The device must be installed by a person trained in the installation
of the apparatus on which the device is to be mounted.
The device mounted on a device can be used (reading of the ten-
sion of the cable) by the gymnasts, coaches, judges or technicians.
The device should only be cleaned with a dry cloth, excluding any
other cleaning product that could damage the device.
Before mounting the device it must be calibrated:
Lay the device fl at without exerting any tension on the quick links.
Press the button 1x to start the device.
Press the button for 5 seconds until the following message is
displayed:
"release and quickly press on the button for calibration"
Release the button then immediately press quickly the button
again to enter the calibration mode. The following message is
displayed:
"calibration mode in progress check that the load is at zero"
The operation takes less than 5 seconds.
You can now connect your device to the tension.
Regular maintenance:
Every use: check security elements aspect: Rings and carabiner
shall not present any damage.
Once a month: External aspect must be checked. Control that no
crack or damage appears on the product.
Once a month: Check the alarm by lowering cable tension below
1.000 N. Alarm must start and blink for 10 sec.
Once a year: Unmount the device and start calibration procedure.
If the device is not used for 3 months, start by charging it or chan- If the device is not used for 3 months, start by charging it or chan-
ging batteries.
Flashing light
(fl ashes at too low
or too high tensioning)
Start button
4. Use
To turn on the device, press the button.
The cable tension is displayed for 5 seconds then the displayed is
turned off .
The device gives the tension in Newton a range from 0 to 10.000
with increments of 100.
If the cable tension is less than 1.000 N or greater than 5.000 N
the LED fl ashes for 10 seconds.
For your own safety: use the apparatus only when the cable
tension is in the range of 1.000 N to 5.000 N.
NOTE: When the device is powered through its USB-C
connector, the display remains active permanently.
The device must be removed from the equipment once a year, in
order to do the calibration procedure.
– 3 –
Display of the battery level +
Display of the voltage in N.
5V DC - 1A
