POWER METER WITH
ADJUSTABLE LCD-DISPLAY
Specifications
Model MGS0101
supply voltage 230 V AC, 50 Hz
maximum current
Voltage range 150V AC - 276V AC
voltage accuracy
Power display range 0,1W - 3680W
Power accuracy
kWh display range 0.000kWh – 9999kWh
Total cost display 0,00€ - 9999€
Power cost display range 00.00€/kWh-99.99€/kWh
Instruction manual
The product has no battery, the cost setting must
be done when the device is plugged in
With the power down protection, all data will be
saved automatically after power off.
RESET
If an abnormal display appears or the buttons show
no response, the device needs to be reset. Press
the RESET button to clear the device's internal
data.
When the device is connected to the power supply,
the display first shows the voltage values in "V".
Press the "MODE" button and the display changes
from voltage "V" to power "W".
Press the "UP" button to display the following data
16A
1. total kWh = total power measured during the
use of the device.
±1%
2. total € = total cost of consumed energy
3. € kWh = This value is adjustable. Use the value
±2%
you personally are paying per kWh.
Press "UP" until the display shows "€ kWh".
Then press "MODE" for about 3 seconds until the
numbers are blinking.
Press "UP" to select a number.
Press "MODE" to move to the next number.
When you have finished setting, press "MODE"
again, the display will change to voltage "V" and
the power meter will start calculating.
If no button gets pressed, the device will
automatically exit the setting mode after 10
seconds.
MODE
UP
Set electricity costs € /kWh
Warnings
This adapter does not convert voltage. Make sure
that your device does not exceed an input range of
230V (nominal power 3680W, 16A).
Do not use covered.
Only for use in dry rooms and do not operate with
wet hands.
To avoid damage, please do not disassemble it by
yourself.
Do not store in direct sunlight, high temperature or
thick dust.
Warranty
On your adapter and for all purchases from NWR,
we provide lifetime technical support.
We are committed to customer satisfaction, so
please feel free to contact us at service@nwr-
business.com with any questions or comments.
Thank you!
NWR-Business
Tobias Niederwieser
Achenseestraße 87a
6200 Jenbach
Austria
Made in China
