Flex FHE 1-16 12-EC Originalbetriebsanleitung Seite 17

FHE 1-16 12-EC
cutting accessories, keep the hands warm,
organization of work patterns.
WARNING:
- that the vibration and noise emissions
during actual use of the power tool can
differ from the declared value depending
on the ways in which the tool is used
especially what kind of workpiece is
processes ; and
- of the need to identify safety measures
to protect the operator that are based on
an estimation of exposure in the actual
conditions of use (taking account of all
parts of the operating cycle such as the
times when the tool is switched off and
when it is running idle in addition to the
trigger time).
CAUTION!
Wear ear defenders at a sound pressure
above 85 dB(A).
Technical data
Tool
Type
Rated voltage
No-load speed
Impact rate
Max. drill diameter
Drilling in wood
Drilling in meatal
Drilling in concrete mm
Impact energy
(according to
„EPTA procedure
05/2009")
Tool holder
Weight according
to"EPTA Procedure
01/2003" (without
battery)
Battery
FHE 1-16 12-EC
Rotary hammer
Vdc 12
/min 0-810
/min 0-4500
mm 13
mm 8
16
J 1.3
SDS-plus
kg 1.4
AP 12/2.5
AP 12/5.0
12V AP 10.8/2.5
AP 10.8/4.0
AP 10.8/6.0
Weight of battery kg
Working
Temperature
Charging
Temperature
Storage
Temperature
Charger
Overview (see figure A)
The numbering of the product features refers
to the illustration of the machine on the
graphics page.
1. Depth gauge
2. Locking sleeve
3. Auxiliary handle
4. LED worklight
5. Function selector
6. Handle
7. Variable-speed trigger switch
8. Direction selector switch (forward/
center-lock/reverse)
9. Depth gauge clamp
10. Belt clip
11. Screw
Instructions for use
Before switching on the power
tool
Unpack the power tool and accessories and
check that no parts are missing or damaged.
NOTE
The batteries are not fully charged on delivery.
Prior to initial operation, charge the batteries
fully. Refer to the charger operating manual.
Inserting/replacing the battery
■ Press the charged battery into the power
tool until it clicks into place (see figure B).
AP 12/2.5
AP 12/5.0
AP 10.8/2.5
AP 10.8/4.0
AP 10.8/6.0
-10~40°C
4~40°C
<50°C
CA 12/18, CA 12
CA 10.8/18.0, CA 10.8
0.3
0.4
0.3
0.4
0.4
17
