Light-Point SPUNK 2 SQUARE Montageanleitung

SPUNK 2 SQUARE
Code 256155
15W
INSTALLATION INSTRUCTION
1．Before installing, make sure the power supply is switched off.
2．Follow the steps as the figure for installation.
A. after holing, pull out the wires.
B. fix the mounting bracket onto the wall with screws.
C. connect the wires to the terminal block.
D. fix the fixture to the mounting bracket with screws.
E. slide the lampshade to the fixture.
3. After finishing every step, tighten the screws, have the fixture fixed,
and then connect the power supply.
CLEANING INSTRUCTION
1. Before cleaning, ensure that the power supply is switched off.
2. Use only a soft cloth to clean the lamp, dampened with mild cleanser
if needed for resistant dirt.
3. Warning: do not use alcohol or other solvents.
CAUTION:
In case of any doubt, please contact the qualified electrician.
NOTE:THIS PRODUCT MUST BE INSTALLED ACCORDING TO LOCAL LAWS AND REGULATIONS!
INSTRUCTION MANUAL
IP54
E
164
140
87.5
15
www .light-point.eu
