Ø45
(Ø1 49/64")
PTR41
DET40
48
(1 57/64")
DET40/DUET
AISI 316L STAINLESS STEEL
Miscelatore monocomando a parete
Wall mounted single handle mixer
DESIGN
MARIO TESSAROLLO / DANIELA LORATO
Prodotto che necessita di parte incasso
Product that needs built-in part
Staffa ausiliaria per cartongesso / fibrogesso
Auxiliary bracket for plasterboard / fiber-board structures
MANUTENZIONE / MAINTENANCE
NON UTILIZZARE
DO NOT USE
UTILIZZARE
TO USE
Questi disegni sono proprietà di CEADESIGN SRL s.u. pertanto non potranno
essere utilizzati e/o comunicati a terzi, anche in forma parziale, senza preventiva
autorizzazione. CEADESIGN SRL s.u. si riserva il diritto di apportare modifiche ai
disegni al fine di migliorare il prodotto.
CEADESIGN SRL s.u. has the property rights on these drawings, therefore they
cannot be used and/or transferred to third party, even in partial form, without any
prior authorization. Furthermore CEADESIGN SRL s.u. reserves the right to apply
any change to these drawings in order to upgrade the product.
_ REV14
PTR
SYSTEM
acido clorico e muriatico
HCl
cloric and muriatic acid
acido fluoridrico
HF
hydrofluoric acid
ipoclorito di sodio
NaCl O
chlorine bleach
detergente a pH neutro
pH
7
neutral pH detergent
ceadesign.it

Werbung

loading

Inhaltszusammenfassung für CEA DUET DET40

  • Seite 1 DET40 Ø45 _ REV14 (Ø1 49/64”) SYSTEM (1 57/64”) DET40/DUET AISI 316L STAINLESS STEEL Miscelatore monocomando a parete Wall mounted single handle mixer DESIGN MARIO TESSAROLLO / DANIELA LORATO Prodotto che necessita di parte incasso Product that needs built-in part PTR41 Staffa ausiliaria per cartongesso / fibrogesso Auxiliary bracket for plasterboard / fiber-board structures...
  • Seite 2 DET40 _ REV14 SYSTEM AVVERTENZE TECNICHE Risciacquare bene le tubazioni prima del montaggio ed evitare sbalzi di pressione fra i raccordi d’acqua fredda e d’acqua calda. In caso di pressioni statiche superiori a 5 bar si raccomanda l’installazione di un riduttore di pressione per evitare danni alla cartuccia.
  • Seite 3 DET40 _ REV14 SYSTEM RICAMBI / SPARE PARTS RICH026 Ghiera / Sleeve RICM120 Maniglia / Handle RICS084 Anello d’arresto / Stop ring RICS084 Conservare gli strumenti inclusi nel prodotto e utilizzati per l’installazione perchè riutilizzabili per i ricambi. Please, keep the tools included in the item pack and employed for its installation, to re-used them for the spare parts.
