Model no.: RC-10
PLEASE READ THE USER GUIDE CAREFULLY
BEFORE USE AND RETAIN FOR FUTURE USE!
This smoke alarm is designed for private homes,
camping trailers and caravan installations.
Safety instructions:
The device comes with a 3V lithium battery.
Batteries are to be handled with care and battery
powered devices should be kept out of reach of
children. Do not try to recharge or burn the batteries.
Technical information:
Diameter: 40mm Height: 41mm
Type of alarm:
Photo electric smoke alarm.
Alarmsignal:
Fire alarm condition is indicated by a series of
repeated tones. The minimum sound level is 85 dB
at 3 meters.
Battery:
Powered by a non-replaceable 3V CR123A Lithium
battery with 10-year life (included).
IMPORTANT: Do not replace the battery. Replace
the product if the battery fails.
Low battery indicator: A short "beep" will sound
and LED flash every 48 seconds when the battery is
near the end of life. In this stage it will continue for
a minimum 30 days. It is recommended to change
the smoke alarm after 10 years, or if the alarm has
suffered any damage. The alarm is not active unless
it is inserted in the mounting base. Always check the
alarm after inserting in the mounting base (allow a
few seconds before testing).
Placement: The smoke alarm is designed for place-
ment on a ceiling or wall. The smoke alarm should
be a minimum of 50 cm from the wall, with a min-
imum of one smoke alarm per floor and a maximum
distance between smoke alarms of 10 meters.
Alarm signal: The alarm has a visual and acoustic
alert tone. In the passive state, the LED will flash
every 48 seconds to indicate normal function. In
an alarming state the LED will flash and the alarm
will emit a sweeping sound pattern design to alert
occupants.
Hush function: In case of unintentional alarm
condition or false alarms, press the top button. This
will hush the alarm for 10 minutes, after which time it
will automatically resume its normal alarm function.
Maintenance: The smoke alarm should be vacuum
cleaned once per quarter, and it can be wiped with a
damp cloth. (Do not open the alarm).
Test the alarm at least once per quarter by pushing
the test button. The alarm will self test and give a
loud alarm tone.
The best places to mount the alarm:
•
Place an alarm between possible fire source
and bedrooms as minimum.
•
Alarms on each floor and in hallways and
stairways.
•
Alarms in each room such as bed rooms and
livingrooms.
•
Install the smoke alarm device in an accessi-
ble location so that you can check the battery
and carry out maintenance work.
Additional alarms increase the security.
Installation of alarm:
1. Detach the alarm from the mounting base by
twisting counter clockwise. Use the mounting base
to mark the screw holes on the ceiling. Use the
enclosed screws and plugs to install the mounting
base. Once the mounting base is installed on ceiling
or wall, attach the alarm by twisting clockwise.
Ceiling
Minimum 50cm from wall
Mark up screw holes with a pen
Use the enclosed screws
and plugs for installation
2. After mounting, test the alarm by pushing the test
button on the top and get a loud alarm tone.
Please note: The label in the product must not be
removed as it contains important information
regarding the product.
The alarm may NOT be placed:
•
In dusty rooms.
•
At the top of high pointed ceilings, in ceiling
corners or within 50 cm of a wall.
•
In rooms where the temperature goes out side
+4°C to 38°C or above 90% relative humidity
not condensing.
•
In kitchen, garage and fireplaces where
damp,gases and smoke could occur. Place
the alarm where it is reachable in order to test
the battery and for maintenance.
Fault finding: If the smoke alarm activates without
visible cause, the possible cause could be:
•
Dust particles in the smoke chamber which
can be removed by vacuuming the mesh.
•
High humidity condensing which can be
resolved by drying the smoke alarm.
If the smoke alarm does not work when the test but-
ton is pushed, the probable cause is a faulty battery
and the smoke alarm must be replaced.
Other information: Do not paint the alarm.
Sound &
Test button
Disposal: For product, please dispose properly at
the end of life. This is electronic waste which should
be recycled.
Chamber
filter
WARNING: All alarms should be assumed as due
to actual fire and the dwelling should be evacuated
immediately.
WARNING: To prevent injury, this apparatus must be
permanently fixed to the ceiling/wall in accordance
Mounting
with the installation instructions.
base
WARNING: Batteries shall not be exposed to
excessive heat such as shine, fire, or the like. Note
the local country regulations regarding installation.
0370
EN 14604:2005 + AC :2008
DoP no.: 102.0024
The DoP document can be downloaded from: www.gloria.de
The paper version of the DoP is available free of charge upon request.
Wall
The CE mark affixed to the product confirms compliance
with all European directives relevant to the product and
in particular with the harmonized requirements of the EN
14604:2005 + AC :2008 standard in accordance with
Construction Products Regulation 305/2011.
All rights reserved: GLORIA shall not be liable for any errors
that may occur in the operating instructions.
Furthermore, GLORIA reserves the right to change the hard-
ware, software and/or specifications stated herein at any
time without notice and GLORIA makes no commitment to
update the information contained herein. All trademarks
referenced herein are the property of their respective owners.
Distributed by GLORIA GmbH, Diestedder Str. 39,
59329 Wadersloh, Germany. info@gloria.de www.gloria.de
Manufactured in China.
For questions or further information:
GLORIA GmbH, Diestedder Str. 39,
D-59329 Wadersloh, Germany
Phone: +49 2523 79349900
www.gloria.de
23
