V2 WF01 Bedienungsanleitung Seite 4

GENERAL WARNINGS: SAFETY -
INSTALLATION - USE
ATTENTION: During the installation of the device it is
important to carefully follow all the instructions in this
manual.
Do not proceed with the installation if you have any doubts
of any kind and request any clarification from the V2
Assistance Service.
CAUTION: Important instructions: Save these instructions
for any future maintenance or disposal of the device.
WARNING: All device installation, connection, programming
and maintenance operations must be carried out by a
qualified technician only!
• Do not open the protective shell of the device as it contains
maintenance-free electrical circuits.
• Do not make any changes to any part of the device.
Unauthorized operations can only cause malfunctions. The
manufacturer declines all responsibility for damage resulting
from arbitrary modifications to the product.
• Do not place the device near heat sources or expose it to open
flames. Such actions can damage it and cause malfunctions.
• The product is not intended to be used by people (including
children) whose physical, sensory or mental capacities are
impaired, or with a lack of experience or knowledge, unless
they have been able to benefit, through the intermediation
of a person responsible for their safety, surveillance or
instructions regarding the use of the product.
• Make sure that children do not play with the product.
• Also check the warnings in the instruction manuals of the
motor with which the product is associated.
• Handle the product with care, avoiding crushing, knocks and
falls to avoid damaging it.
• The product packaging material must be disposed of in full
compliance with local regulations.
• The product must be used indoors or in any case protected
from atmospheric agents.
DISPOSAL OF THE PRODUCT
This product consists of various types of materials: some can be
recycled, others must be disposed of. It is necessary to inquire
about the recycling or disposal systems required by the regulations
in force in your area for this product category.
ATTENTION! - Some parts of the product may contain polluting
or dangerous substances which, if dispersed in the environment,
could cause harmful effects on the environment itself and on
human health.
As indicated by the symbol on the side, it is forbidden to dispose
of this product with domestic waste. Carry out the 'separate
collection' for disposal according to the regulations in force in
your area or return the product to the seller when purchasing a
new equivalent product.
ATTENTION! - The local regulations in force may provide for
heavy penalties in the event of illegal disposal of this product.
DESCRIPTION OF THE PRODUCT AND
INTENDED USE
ATTENTION! Any other use other than that described and in
environmental conditions other than those indicated in this
manual is to be considered improper and prohibited!
The WF01 accessory is a device that, through WiFi
communication, allows the movement and status of V2
automations equipped with ADI connector and compatible with
the operation of this product to be controlled.
ATTENTION: if WF01 is used, the En.SA parameter of the
control unit must be set to OFF.
INSTALLATION
1. Disconnect the power supply to the control unit
2. Insert the module into the ADI port of the V2 control unit
3. At the first installation, make sure that the module is in access
point mode (RED LED ON STEADY)
4. Then proceed to enroll the control panel to the server
following the instructions provided by the V2 GO APP
NOTE: If the module is not in access point mode, reset the
module using the reset procedure: press the reset button for
3 seconds, the LED must go out and light up again, remaining
steady red
STATUS OF LED
• FIXED RED: The module is in Access Point mode, waiting for a
connection
• FLASHING RED: mismatch between the serial of the control
panel and the serial stored in the module. Perform the module
reset procedure
• FIXED BLUE: STA mode, module connected to the server
TECHNICAL FEATURES
Input
Voltage
Current
Max absorbed power
WiFi interface
Type
Power e.i.r.p.
Safety
Environment
Operating temperature
Storage temperature
Humidity
Degree of protection
Dimensions
Weight
- 4 -
15V
45mA
700mW
802.11b/g/n – 2.4GHz
< 100mW
OPEN/WEP/WPA-PSK/WPA2-PSK
-20°C ... +50°C
-25°C ... +70°C
15% - 85%
IP 30
52 x 33 x 13 mm
50 g
