1 Handle
2 Speaker
3 Microphone stand
/
4
On/off – play/pause
5 MODE - Function
6
VOL-/ Volume-
Skip backward
VOL+/ Volume+
Skip forward
8 LED
Light effects
9 EQ / MUSIC
Sound effects
10 USB-jack for playback
11 USB-C for charging
12 LED charge &
Bluetooth indicator
13 AUX IN jack
14
Microphone & voice
canceling on/off
15 + Microphone volume +
16 - Microphone volume -
17 Mic sound effects
18 LED charging indicator
19 MIC-USB-C charging
jack
CONTENT OF DELIVERY

➢ Main unit

➢ Instruction manual
CONNECTING THE USB CHARGING CABLE
➢ Connect the plug of the USB-C charging cable to the DC IN connection of the speaker or
microphone.
➢ Plug the USB connector into a suitable USB port/adaptor ( not supplied).
➢ The LED INDICATOR at the back side will light up (red) while charging and light off when
fully charged.
➢ Note: If you do not need to use the device for a relatively long time, disconnect it from the
power. To do so, unplug the USB cable.

LOCATION OF CONTROLS

INSTALLATION
➢
➢
1
BT2024 / English Instruction Manual
2 x Wireless Microphone
USB-C cable
