INIM QXI-R Serie Installationsanleitung
INIM QXI-R Serie Installationsanleitung

INIM QXI-R Serie Installationsanleitung

Weitwinkel auflenmelder batteriebetriebene modelle
Verfügbare Sprachen
  • DE

Verfügbare Sprachen

  • DEUTSCH, seite 5
Wide Angle Outdoor Detector
Wide Angle Outdoor Detector
QXI-R series
QXI-R series
BATTERY OPERATED MODEL
Introduction
1
Manufacturer' s statement
2
! Warning
Installation
3
Do not touch the
!
parts with this sign.
Base
Main unit
Cover
LED
[1] Warm-up
Lens
[2] Alarm
[3] Walk test end
How to open the cover
Lock screw
(Use as necessary)
* Remove before,
if used.
[1] Unlock the cover using a
screwdriver (-).
[2] Lift the cover up.
PDF download and additional information with multilanguage
available in:
https://inim.biz/it/antintrusione/protezione-da-esterno?
Prohibited
Recommended
Mounting height
Multi Level
Pet Alley
MaximumTransmitter
Size
(mm)
Microwave module
30
!
50
Tamper switch
90
Seconds
60
2
5
Battery Life
Unit: estimated years
(DIP SW No.5)
120
Battery saving timer
CR123A
4
(3 V DC, 1300 mAh)
Air2-UT100/S battery
6
ER17505M
(3.6 V DC, 2800 mAh)
Battery sharing
Wall tamper option
QXI-RDT-X5-NB: +Microwave detection (10.525 GHz)
! Caution
2.2 m (7 3 ) to 2.7 m (8 11 )
0.8 m (2 7 ) to 1.2 m (4 )
MW Sensitivity
!
L
H
Default
Mirror
Except levers
!
on side
DIP switch
PIR sensor
!
Cover lock screw
(Use as necessary)
5
3
4
(See Web manual for details)
[1] Install dummy battery
in transmitter
[2] CR123A
- 1 -
INSTALLATION INSTRUCTIONS
Tilt
Remove unused battery in case of battery sharing.
(See Web manual for details)
Connectors
Main unit side
Transmitter side
Red
Power
Black
White
Alarm
Yellow
Green
Trouble
Blue
<Accessories>
Dummy battery
and Connector for
ALARM
Connector for sharing
of the transmitter's battery
(See Web manual for details)
Mounting screw
(4 × 20 mm) x 3
Area masking strips
a
b
b
c
c
d
d
e
e
<Options>
CA-1W(W)
Bracket for wall mount
QXI-RDT Air2-UT100/S
Red
"+" (3.6V)
Red
Black
"-" (3.6V)
Black
White
White
"-"
Yellow
Yellow
"1"
Green
"T"
Green
Blue
Blue
"-"
Connector for
TROUBLE
Fixing screw
for the Main unit
(3 × 12 mm) x 1
e
d
c
b
a
b
c
d
e
CA-2C(W)
Bracket for ceiling mount
loading

Inhaltszusammenfassung für INIM QXI-R Serie

  • Seite 5 INSTALLATIONSANLEITUNG Weitwinkel Außenmelder Weitwinkel Außenmelder QXI-R serie QXI-R serie Batteriebetriebene Modelle QXI-RDT-X5: +Mikrowellendetektion (10.525 GHz) Einführung PDF-Download und zusätzliche Informationen in mehreren Sprachen finden Sie unter der angezeigten URL: https://inim.biz/it/antintrusione/protezione-da-esterno? Herstellererklärung Verbot Empfehlung Warnung ! Vorsicht Montagehöhe Multi Level 2,2 m bis 2,7 m Schräg...
  • Seite 6 2,0 ±0,5 Sek. Alarmdauer Aufwärmphase Ca. 60 Sek. (LED blinkt) ■ Inim Electronics S.r.l. bestätigt, dass QXI-RDT-X5 der Funkanlagen Alarmausgang Öffner/Schließer wählbar, Halbleiterrelais 3 V DC 0,01 A max. -Richtlinie 2014/53/EU entspricht. Das vollständige Dokument ist auf folgender Fehlerausgang Öffner/Schließer wählbar, Halbleiterrelais 3 V DC 0,01 A max.
