Polk Audio RM6504-1 Bedienungsanleitung Seite 12

Figure A
SUBWOOFER
CENTER CHANNEL
LEFT CHANNEL
RIGHT CHANNEL
Y
X=Y=Z
Z
X
REAR SPEAKERS
Figure B
LEFT
CHANNEL
CENTER CHANNEL
Figure C
CENTER CHANNEL
LEFT CHANNEL RIGHT CHANNEL
Y
X=Y=Z
X
Z
REAR SPEAKERS
RIGHT
CHANNEL
SUB-
WOOFER
SUBWOOFER
Figure D
Subwoofer
OK
AMPLIFIER SIDE
LADO DEL AMPLIFICADOR
CÔTÉ AMPLIFICATEUR
VERSTÄRKER SEITE
OK
AMPLIFIER
AMPLIFICADOR
AMPLIFICATEUR
VERSTÄRKER
AMPLIFIER
AMPLIFICADOR
AMPLIFICATEUR
VERSTÄRKER
AMPLIFIER
AMPLIFICADOR
AMPLIFICATEUR
VERSTÄRKER
9
