REPLACEMENT PARTS LIST
Important Safety Notice
Components Identified by
characteristics important for safety.
When replacing any of these components, use only
manufacturers specified parts.
* In case of ordering these spare parts, please
always add the complete Model-Type number to
your order.
Cct Ref Parts Number Description
COMMON PARTS
MECHANICAL PARTS
1 EASG15S506A2 SPEAKER
2 ENG29505GR TUNER
3 EUR511211 REMOTE CONTROL
4 TBM8E1928 PANASONIC BADGE
5 TBX8E078 POWER BUTTON
6 TKP8E1301 REAR AV PANEL
7 TKP8E1308 DOOR LID
8 TKU8E00600 BACK COVER
9 TKY8E502 CABINET
10 TMW8E031 CONTROL BRACKET
11 TMX8E037 CHASSIS FRAME
12 TNP8EF007AB F P.C.B.
13 TNP8EM021AC M P.C.B.
14 TNP8EP017AB P P.C.B.
15 TNP8EY018AE Y P.C.B.
16 TSX8E0033 POWER CORD
17 TXFLK01DAG DEGAUSS COIL
18 TXJ/FC0DEG FOCUS LEAD ASSY
19 UR51EC904A BATTERY COVER (REMOTE)
20 VP17005-32 CRT FIXING SCREW
21 W66EHK51X81 C.R.T.
22 ZTBZAD550A ANODE CABLE
23 ZTFM05009A F.B.T.
MISCELLANEOUS COMPONENTS
. 832AG11D-ESL IC SOCKET
. PCSZT-084A-1 IC SOCKET
. TBM8E1942 AV PANEL LABEL
. TBM8E1976 PRESET LABEL (L)
. TBM8E1977 PRESET LABEL (R)
. TEK6940 LID CATCH
. TES8E019 POWER BUTTON SPRING
. TKP8E1310 IR COVER
. TMW8E030 LED HOLDER
. TMX8E041 PCB BRACKET
. TPC8E4824 CARTON
. TPD8E724 TOP CUSHION
. TPD8E725 BOTTOM CUSHION
. UM-3DJ-2P BATTERY PACK
R802 232266296706 THERMISTOR
I.C.s
IC251 LA4282 AUDIO OUTPUT
IC351 TDA6111Q-N4 RGB OUTPUT
IC361 TDA6111Q-N4 RGB OUTPUT
IC371 TDA6111Q-N4 RGB OUTPUT
All manuals and user guides at all-guides.com
mark have special
16
ERSATZTEILLISTE
Wichtiger Sicherhitshinweis
Teile, die mit einen Hinweis
wichtig für die Sicherhet. Solite ein Auswechsein
erfordelrich sein, sind unbdingt Originalteile
einzusetzen.
Bei der Bestellung von Ersatzteilen, di mit *
gekennzeichnet sind, geben Sie bitte unbedingt die
vollständige Typenbezeicnung mit an.
Cct Ref Parts Number Description
IC381 TL431CLPM REGULATOR
IC451 LA7876N VERTICAL OUTPUT
IC601 TEA2114 VIDEO SWITCHING
IC701 TEA2031A E/W CORRECTION
IC801 STRF6656LF57 POWER SUPPLY
IC850 SE140N ERROR AMPLIFIER
IC851 AN7812LB1 12V REGULATOR
IC852 L78M09MRB 9V REGULATOR
IC853 AN78L08TA 8V REGULATOR
IC855 BA033T-M3 REGULATOR
IC856 AN7805LB 5V REGULATOR
IC1061 RPM-637CBRL LED RECEIVER
IC1101 SDA5450C59 MICRO PROCESSOR
IC1102 27C2001-N01 EPROM *
IC1104 MN1381-R(TA) RESET
IC1105 MN1381-T(TA) RESET
IC1501 VPC3215CB8TP VIDEO PROCESSOR
IC1502 CIP3250APSB1 C.I.P.
IC1503 SDA9400 MICRO PROCESSOR
IC1504 DDP3310BPSE4 VIDEO PROCESSOR
IC2101 MSP3410DPOC5 AUDIO PROCESSOR
FUSES
F802 19181-3.15 FUSE
F802-1 EYF52BC FUSE HOLDER
F802-2 EYF52BC FUSE HOLDER
DIODES
D101 MA3020TX DIODE
D102 MA3020TX DIODE
D251 MA2180BLFS DIODE
D253 MA700TA5 DIODE
D254 MA700TA5 DIODE
D351 ERA15-04V3 DIODE
D352 ERA15-04V3 DIODE
D361 ERA15-04V3 DIODE
D362 ERA15-04V3 DIODE
D371 ERA15-04V3 DIODE
D372 ERA15-04V3 DIODE
D376 MA165TA5 DIODE
D377 MA165TA5 DIODE
D378 MA165TA5 DIODE
D387 MA2160LFS DIODE
D453 MA165TA5 DIODE
D454 EU02 DIODE
D456 MTZJT-775.6C DIODE
D457 MA165TA5 DIODE
D458 EU02 DIODE
D501 MA165TA5 DIODE
D502 1SR124-4AT82 DIODE
D511 MTZJ4.7C DIODE
D553 1SR124-4AT82 DIODE
D554 1SR124-4AT82 DIODE
D556 MA165TA5 DIODE
gekennzeichnet sind
