Parts list
A. Car body
C. Backrest
B. Handlebar
D. Side guard
Mounting procedure
•
Insert the handlebar and make sure it is firmly seated.
•
Press the button and pull out the pedals.
•
Insert the pedals onto the body bases, making sure that the small ring is inserted into
the body frame when inserting the pedal.
•
Press down the lower button and take the rear wheels apart.
•
First pull up the knob and then turn the rear wheel outwards.
•
Insert the backrest into the saddle and listen for a "click" to make sure it is properly
seated.
•
Insert the push bar into the rear receptacle and listen for a "click" to make sure it is
seated properly.
Attention! When the tricycle is pushed or propelled, the holes in the front wheel must be
•
closed with the covers.
•
First insert the vertical bar into the front end of the saddle and clamp both ends of the
protector into the slot in the backrest. Finally, turn the knob to complete the installation.
Remove protection
First turn the knob as shown in the illustration, pull out the armrests upwards on both sides, then
press the stuck point at the bottom of the saddle and pull out the vertical bar to release the
entire guard.
Adjusting the handlebar tilt
When you adjust the angle forward, pull the knob up and push the handlebar forward at the
same time, and then remember to pull the handlebar up a little until you hear "clack", which
means that this position is locked. If you want to straighten the angle again, just pull the knob
up and pull the handlebar back and it will be fine.
Adjusting the height of the push bar
First pull up the safety lock button in the middle of the push bar, then push down the button in
the middle of the handle, at the same time push down the push bar to reduce the height or
pull up to extend the height of the push bar. There are 3 height settings. When the height
adjustment is complete, press the safety button to prevent the push bar from wobbling.
Adjusting the seat height
Loosen the screw with a screwdriver to adjust the height and then tighten the screws. Make
sure it is tight!
Hergestellt für Dilaw Warehouse GmbH // Fuggerstraße 15a // 48165 Münster // Germany
12
E. Two pedals
G. Screwdriver
F. Push bar
H. Plastic ring
www.eshopping.de
I. Front wheel
J. Bell, Drink
holder, Mirror,
Bag
