The signal flash 30516 is a dual purpose water-proof light. One end is a signal flash light and the
other end is a torch. The flash light can be seen about 2 km away. It can be used for diving up to 40 m
deep.
Attention:
HOW TO LOAD BATTERIES:
1. Unscrew the signal flash cover from the body.
2. Take out the battery holder by using a finger to pull out as per
diagram.
3. Insert 3 pcs. AA size alkaline batteries in the holder according to
the polarity signs in the holder.
4. Put back the holder into the body by following the arrow signs on
the holder and body. There is a rib in the body for the holder to glide
into the body.
5. Lubricate the O-rings with silicone greese.
6. Screw back the signal flash cover on the body.
ON/OFF SWITCH:
It's a magnetic switch specially designed for water-proof. Turn the
switch ring to the RIGHT side with the „flash" mark, the signal flash
will be switched on and flashes. Turn the switch ring to the LEFT with
the „light" sign, the torch will be switched on. In between these two
signs is the OFF position.
REMARKS:
1. The flash tube, torch LEDs and the reed switch inside this light are
all made of glass. High impact will damage the glass. Therefore,
please do not let the light hit on hard objects or drop it on hard floor.
2. Please take out batteries if store for long time.
3. Before use, please check batteries whether they are in good condition. If the light of the torch
become dull and yellowish color, batteries have run-down and not enough power, please change for
new batteries.
4. In case of stop functioning, be sure not to repair by yourselves, because of the high voltage in the
signal flash circuit. Repair must be handled by specialist. Please send back to us by agent for repair.
SPECIFICATIONS:
MATERIALS
WATER PROOF
VISIBILITY
POWER SOURCE
FLASH PERFORMANCE
TORCH ONLY
SWITCH
MEASUREMENT
WEIGHT
Spare parts
Art. N°
30516-001
30516-002
30516-003
30519-004
30516-005
30516-006
30516-007
30516-008
Seemann Sub GmbH & Co KG, Johann Höllfritsch Straße 47, 90530 Nürnberg, Germany
Don't screw the clear caps too tight !
Flash & torch covers of acrylic, body of ABS
Up to 4 atmospheric pressure (40 meters deep)
2 km for flash - about 100 meters for torch
3 pen-light alkaline batteries
Continuously flashing for 10 hours of 3-4 seconds per flash
About 2 hours
Magnetic reed switch
∅ ∅ ∅ ∅ 47 x 136 mm
160 g without battery
Name of item
Strobe Cover
Strobe Module
Seal Kit
Battery Compartment
Body
LED Flashlight Module
LED Flashlight Cover
Lanyard
SIGNAL FLASH 30516
Instruction
