Instruction manual – ChiliTec Art. No. 20629 Version 05-2024
Don't plug in an appliance where the load exceeds 16 Amp. Always ensure the plug of any appliance is
fully inserted into the timer outlet. If cleaning of the timer is required, remove from main power and wipe
the timer with a dry cloth.
DO NOT IMMERSE TIMER IN WATER OR ANY OTHER LIQUID.
Heaters and similar appliances should never be left unattended during operation. The manufacturer re-
commends such appliances not be connected to timers.
BRIEF INTRODUCTION
1. The Timer has a total of 8 ON/OFF programs.
2. MANUAL ON/AUTO/MANUAL OFF can make settings as required very easily.
3. 12/24 hour mode is switchable.
4. Summertime function is very useful for areas with summertime system.
5. 16 combinations of day or blocks of days are available for this Timer as follows:
Mo
Tu
We
Th
Fr
Sa
Su
Mo, Tu, We, Th, Fr, Sa, Su
Mo, Tu, We, Th, Fr
Sa, Su
Mo, Tu, We, Th, Fr, Sa
Mo, We, Fr
Tu, Th, Sa
Mo, Tu, We
Th, Fr, Sa
Mo, We, Fr, Su
INITIAL OPERATION
1. Plug the Timer into a regular 230/240 Volt household power point and turn the power on.
2. Leave for approximately 12 hours to charge the Memory Back Up batteries.
3. After charging clear all current information by pressing the R (master clear) button with a sharp object
such as a pen or pencil.
4. The timer is now ready to be set up for use.
SETTING CURRENT TIME
1. Press the C+ (clock) button and hold, simultaneously press the W+ (week) button until the actual day is
displayed. Continue by pressing H+ (hour) or M+ (minute) button until the current hour or minute is dis-
played. When setting, the buttons W+ (week), H+ (hour) or M+ (minute) can be held down for rapid for-
ward counting.
2. Release both buttons. The week and time will be set.
3. To reset incorrect time, repeat previous steps.
SETTING PROGRAMS
1. Press the
(timer) button and release. The first ON setting can be made now.
2. Press W+ (week) button to set the day or blocks of days. Set the time by pressing the H+ (hour) button
and then M+ (minute) button.
3. Press the
(timer) button again to finish the first ON setting and enter into the first OFF setting. By re-
peating 2 to make the first OFF setting.
4. Press the
(timer) button again to finish the first OFF setting and enter into the 2nd ON setting.
Vervielfältigung nur mit Genehmigung durch
ChiliTec GmbH, Bäckerberg 12, 38165 Lehre
Amtsgericht Braunschweig, HRB 201747
Instruction Manual
Stand: 05/2024 - Version 1.00
EAR (WEEE): DE25841852
LUCID VerpackG: DE5562476395648
GRS (UBA-Register) Nr.: 21003466
Seite 5
Art.-Nr. 20629
