Additional functions for the CombiStar 7250 simplex
To open with a timed delay, the CODE will have to be entered once again after the timed
delay has elapsed. If the CODE is not entered again within the prescribed period, then opening
with timed delay will have to be repeated from the beginning.
Timed delay
Timed delay
Timed delay
Enter CODE 1 or 2
Timed delay perid
set for 6 minutes
Activate timed delay (only when the electronic lock is open,
start within 10 seconds after opening the lock):
Deactivate timed delay (only when the electronic lock is open,
start within 10 seconds after opening the lock):
Opening with timed delay
Wait for 15 x then
_________________________________________________________________________________________________
B7250_simplex_E_01.doc
1 - 3 minutes>
4 - 10 minutes>
11 - 99 minutes>
Sequence of functions timed delay set for 6 minutes
CODE 1 (example shown here)
Desired time period (from
CODE 1 (example shown here)
CODE 1 or 2 (example shown here)
1
green Delay time has elapsed; release period starts.
Enter CODE 1 or 2 once again
If an incorrect CODE is entered during the release
period, or if
timed delay will have to be restarted from the beginning.
Rel. 1 vom 01.07.2005
Release period 1 minute
Release period 2 minutes
Release period 3 minutes
Enter CODE 1 or 2 again
within the release period
Release period is
2 minutes at time delay periods
of from 4 to 10 minutes
(to
is pressed, then the procedure for opening with
User's Manual No. 9999-064-0
Open the lock within
10 seconds after the
entering the second CODE
10-seconds time period
cannot be changed
for 1 minute)
for 99 minutes)
