FULL VERSION MANUAL
COMMUTE
Art.no 37313-2, 37313-3, 37313-4, 37313-5
Thank you for choosing Silva Commute Bike Light. Commute is
designed to meet the demands of today's biker or commuter. It
will ensure visibility in traffic, light the way forward and is easy
to attach to the bike handle bar. e and more speed.
PRODUCT OVERVIEW
The Commute bike light consists of the following parts:
• Lamp body with silicone strap
• 3 pcs AAA batteries
• Quick guide
BEFORE USE
INSERT BATTERIES
1. Open the lid at the bottom of the light unit by pressing the bat-
tery lid release button and gently pull the lid and the battery
compartment out.
2. Insert the 3 AAA batteries. When inserting the batteries,
please note the battery polarity. Inserting the batteries the
wrong way may cause permanent damage to the product or
even fire. Always replace all batteries when they are flat and
always use 3 batteries of the same brand.
3. Assembly by putting the battery compartment back into the
light.
4. Ready!
DURING USE
SWITCH ON YOUR COMMUTE
On top of the lamp there is a push button that controls the differ-
ent light modes.
Available light modes are: Max, Min and Blink
Each press on the button gives you the following light:
4
1. Turns the lamp ON with the LED in maximum power.
2. Puts the lamp in min mode
3. Flash function
4. Starts over from 1
To turn OFF the lamp; press and hold the button for 1 second.
ATTACHMENT
Commute is designed to be used on the bike handle bar with a
diameter of 25 to 32 mm.
AFTER USE
MAINTENANCE
To make sure you get maximum performance from your Com-
mute bike light, clean it regularly with a damp cloth.
If stored for a long period the batteries should be removed.
TECHNICAL SPECIFICATIONS
Weight (including batteries): 65 grams
Battery type: 3 pcs AAA alkaline
Light distance (Max/Min): 32 meters / 19 meters
Lumen: 45
Burn time: Max/Min/Blink: 20 hours/50 hours/100 hours
Water resistance: IPX4
Operative temperature range: -20 - +60 ºC
PROTECT THE ENVIRONMENT.
Headlamp and batteries should be recycled and must not be
thrown in the regular trash. Dispose these items in accordance
with applicable local regulations.
WARRANTY
Silva warrants that, for a period of two (2) years, your Silva
Product will be substantially free of defects in materials and
workmanship under normal use. Silva's liability under this war-
ranty is limited to repairing or replacing the product. This limited
warranty extends only to the original purchaser.
If the Product proves defective during the Warranty Period
please contact the original place of purchase. Make sure to have
your proof of purchase on hand when returning the product.
Returns cannot be processed without the original proof of
purchase. This warranty does not apply if the Product has been
altered, not been installed, operated, repaired, or maintained
in accordance with instructions supplied by Silva, or has been
subjected to abnormal physical or electrical stress, misuse,
negligence or accident. Neither does the warranty cover normal
wear and tear. Silva is not responsible for any consequences,
direct or indirect, or damage resultant from use of this product.
In no event will Silva's liability exceed the amount paid by you
for the product. Some jurisdictions do not allow the exclusion or
limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you. This Warranty is
valid and may be processed only in the country of purchase.
For more information please visit www.silva.se
5
2
3
4
5
Visit: www.silva/enviroment
for more information about the
Waste Electrical and Electronic
Equipment (WEEE) Directive.
