Set up your Key Light
Screw Key Light directly onto the pole via the integrated socket and screw. Extend the pole to
your preferred height.
A non-slip rubber washer is included for mounting a camera, camcorder, etc. It is recommended
that you remove it when mounting Key Light.
Do not overtighten.
Push the button to position the
ratchet after tightening.
Tighten Loosen
Loosen Tighten
Padded and expandable
up to 6 cm / 2.35 in
1
Maximum load 2 kg / 4.5 lbs
Minimum 55 cm / 22 in
Maximum 125 cm / 49 in
(90 cm / 35 in recommended)
It is normal for the pole to
shake when fully extended.
Connect the power supply and
plug it into a power outlet.
I = ON 0 = OFF II = RESET
