Before Initial Operation; Charging Battery Rechargeable; Charging Cradle; Initial Operation - Seto FLASHLIGHT FC LED RECHARGEABLE 2.0 Gebrauchsanleitung

INFORMATION!
For luminaires with rechargeable battery
The rechargeable battery is partially charged when delivered. Before use, the rechargeable battery must only be
charged in the installed state using the luminaire, the supplied charging cradle (I), the USB-C charging cable and
the suitable charging plug so that you have the full lighting duration.
Only charge the rechargeable battery (C) using the charging cradle (I) and USB-C charging cable (K) included in the scope
of delivery. To do this, place the luminaire on the charging cradle (I) with the charging contacts (H) facing downwards and
plug it in. You can recognize the correct fit by the metallic clicking sound. Connect the USB-C charging cable (K) to the
USB-C charging port (J) on the side of the charging cradle (I) and connect the USB-C charging cable (K) to the supplied
USB mains adapter or USB car adapter (when charging in the vehicle).
Note: The luminaire can be operated during charging.
Status display
During the charging process, the respective charge status point of the capacity indicator flashes.
When fully charged, all charge status points light up constantly.
WARNING!
Charging must only be carried out in dry rooms.
The charging cradle can either be placed on a flat surface, e. g. a table-top, or attached to a wall by screwing or sticking
it on. Thanks to the Velcro system supplied, no screws are required in the vehicle.
1. The luminaire must be switched off before inserting the rechargeable battery (C).
2. Unscrew the closing cap (F) anti-clockwise and insert the rechargeable battery (C) into the luminaire with the
positive pole first (side with indentation). Replace the closing cap (F) in the light housing and screw the
luminaire back on tightly.
Caution: The light will not work if the rechargeable battery is inserted
incorrectly.
3. To switch on and off, press the ON / OFF switch (E).
4. Hold the luminaire body firmly and slide the lens head (A) forwards and
backwards to set the desired light cone (see drawing on the right).
5. Multiple function:
A single press of the switch (E) switches through the various light modes in
the sequence 100 % – 50 % – OFF. A long press switches the luminaire off in
each lighting mode.
12

Before initial operation

Charging rechargeable battery

Charging cradle

Initial operation

78° 24°
