Input voltage
Operating temperature
Humidity/operation
Power factor correction filter
Form factor
Protection functions
Certification
4 Installation
1. Attach the power supply unit to the designated place in your PC case using
PC-Gehäuse mit entsprechenden Schrauben.
2. Connect the ATX 20+4 pin connector (a) to the corresponding 24 or 20 pin
connector on your mainboard.
3. Connect the 4+4 pin CPU connector (b) to the corresponding 4 or 8 pin
connector on your mainboard.
4. For PCI/PCIe expansion cards, use a 6-2 pin connector (c). Connect the
corresponding modular cable harness to the power supply unit.
5. Optical drives and HDD/SSD are connected with a 15-pin SATA
connector (e) or 4-pin Molex connector (d) depending on their design, floppy
drives or peripherals with a corresponding connection are connected with the
4-pin floppy connector (f). Connect the corresponding modular cable harness
to the power supply unit.
6. Close your PC case.
7. Connect the IEC plug to the power supply unitand connect it to a power
source.
8. Switch on the power supply unit and then switch on your PC.
English
100 ~ 240V AC, 47 ~ 63Hz
5° ~ 60° C
20% ~ 85%
ActivePFC
ATX12V
OVP, UVP, SCP, OPP, OCP, OTP
CE, 80PLUS® Gold
11
