Konnektivität
Frequenzbereich
MAX� HF-Leistung
Bluetooth®
WLAN
Mobilfunknetz
GNSS
Bake
Bluetooth®
WLAN
Mobilfunknetz
GNSS
Bake
2400MHz ~ 2483�5MHz
2400MHz ~ 2483�5MHz
GSM:EGSM 900:Uplink:880-915MHz,Downlink:925-960MHz
DCS 1800: Uplink:1710-1785MHz,Downlink:1805-1880MHz
WCDMA: BAND I: Uplink:1920-1980MHz,Downlink:2110-2170MHz
BAND VIII: Uplink:880-915MHz,Downlink:925-960MHz
LTE:
E-UTRA BAND 1: Uplink:1920-1980MHz,Downlink:2110-2170MHz
E-UTRA BAND 3: Uplink:1710-1785MHz,Downlink:1805-1880MHz
E-UTRA BAND 7: Uplink:2500-2570MHz,Downlink:2620-2690MHz
E-UTRA BAND 8: Uplink:880-915MHz,Downlink:925-960MHz
E-UTRA BAND 20: Uplink:832-862MHz,Downlink:791-821MHz
E-UTRA BAND 28: Uplink:703-748MHz,Downlink:758-803MHz
E-UTRA BAND 38: Uplink:2570-2620MHz,Downlink:2570-2620MHz
E-UTRA BAND 40: Uplink:2300-2400MHz,Downlink:2300-2400MHz
Available frequency bands for LTE Band 28 in Europe are 703-736MHz(TX),
758-791MHz(RX)
GPS L1 C/A:1575�42MHz±1�023MHz BeiDou B1I: 1561�098 ±2�046 MHz
(G1/G1-2000)
CH9:7987�2MHz
≤20dBm
≤20dBm
EGSM 900: 25 dBm to 35 dBm
DCS1800: 22 dBmto 32 dBm
WCDMA:+24dBm+1�7/-3�7dB
LTE: E-UTRA Band28:23dBm+2�7/-3�2dB other Bands:23dBm±2�7dB
Nur Empfang, aber kein Sendebetrieb (G1/G1-2000)
≤0dBm/50MHz
47 DE
