Installation Guide

4.2 EvoFlat 4.0 F. Construction and Diagrams.

36
1 2
96 65 65 65 65 65 65 44
Connections:
1. Domestic cold water (DCW) inlet
2. Domestic hot water (DHW)
3. Domestic cold water (DCW) outlet
4. District heating (DH) supply
5. District heating (DH) return
6. Heating (HE) supply
7. Heating (HE) return
Options:
• PWH- Circulation set (183H0500)
• Actuator TWA-Q NO 230V (082F1601)
DHW
DCW
59
DCW
12
7
DHW-C
DH
Supply
24
DH
Return
8 | © Danfoss | HydronicS | 2023.11
EvoFlat 4.0 Flat Stations for apartments, single- and multi-family houses
69
3 4 5 6 7
530
2
33
38
33
9 4
23
40
23
17
59
2
4
5
7
9
12 Safety valve
17 Air vent
23 Sensor pocket
24 Fitting piece for energy meter 3/4" × 110 mm
38 Hot Water Controller
40 Summer By-pass
52 Zone valve
52A TWA Q-NO 230V for zone valve (optional)
59 Fitting piece for water meter 3/4" × 110 mm
17
5
52A
4 52
2
52A
4 38
5
24
Plate heat exchanger DHW
Differential pressure controller
Stainer
Ball valve
DHW circulation set with safety valve
~ 230 V
AN40274706699301-010102
52
4
40
HE
Supply
HE
Return
