SCOPE OF DELIVERY

Check the delivery for completeness and perfect condition.
In the case of missing parts or damage:
• do not mount the unit!
• do not put the unit into operation!
• make a complaint to the supplier.
The deliver consists of:
• Product
• Mounting material (2x screws, 2x clips)
• Instructions
• Power cord
• Accessories (Connecting cable, connecting piece)

TECHNICAL DATA

Type Output
LG05K-03-04 4W
LG05K-06-08 8W
LG05K-09-12 12W
LG05K-12-14 14W
• These products contain a light source of energy efficiency class F
• Illuminant: SMD LEDs
• Luminous efficacy: 100lm/W
• Colour temperature: 4000K
• Colour rendering index (Ra/CRI): ≥ 80
• LED service life: 30000h
• Beam angle: 120°
• IP protection class: IP20
• Protection class: II (S7)
• Ambient temperature: -15°C - 40°C
INSTALLATION
• Please refer to the drawings for the installation steps.
CLEANING
• Allow the luminaire to cool down sufficiently!
• Before cleaning, unplug the product from the power point or disconnect it from the mains supply!
• Clean with a dry or slightly moist, clean, lint-free cloth and a mild detergent if required. Do not use cleaners that
contain abrasives or solvents.
MAINTENANCE
• Remove all dirt from the housing or protective panel immediately, as this can lead to overheating.
• The light source of this luminaire is not replaceable; if the light source has reached the end of its service life, the
entire luminaire must be replaced.
Light source not
1
interchangeable!
10
Luminous Nominal data
flux
400lm 230V~ / 50Hz / 0,055A
800lm 230V~ / 50Hz / 0,11A
1200lm 230V~ / 50Hz / 0,11A
1400lm 230V~ / 50Hz / 0,095A
LED LED
1
Dimension
(WxHxD) in mm
312x22x32
572x22x32
872x22x32
1172x22x32
Control gear not interchangeable
2
(ballasts, power supply units, etc.)!
Weight
60g
90g
125g
160g
