S
P
L
T I
SPLIT
SPLIT
To split the keyboard in two parts all you do is press the key wish to be the
dividing point on the keyboard then press the switch «SPLIT».
Obviously once split, the keyboard is separated in two distinct parts, the LOWER
part will go through channel MIDI 1 and the UPPER part through channel MIDI 2.
If you press only «SPLIT» and no key the entire keyboard will transmit trough MIDI 1
TRANSPOSER
LOWER: to transpose the LOWER part of the keyboard press the note you want to
correspond to initial A then press the switch «LOWER».
UPPER:to transpose the UPPER part of the keyboard press the note you want to
When you split, transposition will be automatic, the lower part will increase by one
octave and the upper part decreases by one octave.
TECHNICAL DATA
Supply will require a standard adapter with a variable continuous out put voltage
ranging 9 to 12 V and 350 mA current minimum.
The keyboard includes two midi outputs to pilot other instruments.
Ther is also a FOOT-SWITCH jack to wich you can connect an OFF-ON pedal wich
on the market.
4
STUDIO 90
STUDIO 90
T
R
A
N
S
P
TRANSPOSER UPPER
TRANSPOSER
LOWER UPPER
MIDI OUTS
FOOT - SWITCH
POWER INPUT
O
S
E
R
L
O
W
E
R
ON
OFF
izers and expanders
