Appendix A Drawings & Technical data
Figure A1: Dimensions
Table A.1. Dimensions
A
B
C
D
E
F
G
H
K
L
'
REHOBOT Hydraulics AB
PH70A-600
PH80A-600
mm
in
590
23.2
170
6.7
90
3.5
68
2.7
56
2.2
540
21.3
68
2.7
84
3.3
7
0.28
6.6
0.26
Skjulstagatan 11 A, 632 29 Eskilstuna, SWEDEN P.O. Box 1107 631 80 Eskilstuna
T. +46 (0)16 - 16 82 00 F. +46 (0)16 - 13 93 16 info@rehobot.se www.rehobot.se
PH70A-1000
PH80A-1000
mm
in
590
23.2
170
6.7
110
4.3
80
3.1
75
3.3
575
22.6
68
2.7
84
3.3
7
0.28
6.6
0.26
