Liftek PG701 Montageanleitung

Vorschau ausblenden
Diese Anleitung herunterladen
1
2
Power Windows
Leve-glace Electrique
Elektrische Fensterheber
Elevalunas Electricos
Alzacristalli Elettrici
front doors (4d), portes avant (4p), vordere türen (4t), puertas anteriores (4p),
porte anteriori (4p)
Pour / For
Peugeot
Peugeot 207 (05/2005>)
Solo meccanismo / Mechanical part only -
Lato guida / Driver side - Left hand drive
/ Right hand drive] [Con funzione comfort
/ With comfort function
LH Guida sinistra / Driver side
RH Guida destra / Driver side
LH Left hand drive
RH Right hand drive
LH 9221X1
RH
LH Solo meccanismo / Mechanical part only
RH Solo meccanismo / Mechanical part only
left door - portière gauche - linke tür - puerta lado izquierdo - porta lato sinistro
USE THIS INSTALLATION INSTRUCTION ALSO FOR THE OPPOSITE SIDE.
UTILISER CETTE INSTRUCTION DE MONTAGE AUSSI POUR L'AUTRE COTE.
BENUTZEN SIE DIESE MONTAGE-ANLEITUNG AUCH FÜR DIE ANDERE SEITE.
EMPLEAR ESTA INSTRUCCION DE MONTAJE TAMBIEN POR EL OTRO LADO.
LA PRESENTE ISTRUZIONE VALE ANCHE PER L'ALZACRISTALLI DELLA MANO OPPOSTA.
PG701
loading

Verwandte Anleitungen für Liftek PG701

Inhaltszusammenfassung für Liftek PG701

  • Seite 1 Power Windows Leve-glace Electrique Elektrische Fensterheber Elevalunas Electricos Alzacristalli Elettrici front doors (4d), portes avant (4p), vordere türen (4t), puertas anteriores (4p), PG701 porte anteriori (4p) Pour / For Peugeot Peugeot 207 (05/2005>) Solo meccanismo / Mechanical part only -...
  • Seite 2 PG701 3-03-2008 ENGLISH ENGLISH USE THIS INSTALLATION INSTRUCTION ALSO FOR THE OPPOSITE SIDE. A) Disassemble door panel. Drill out the fixing rivets and remove the regulator. Drill into positions 1 and 2 (ø 6,5 mm.). B) Remove the pvc gear clamp from the motor plate (photo A). Insert the motor into positions 6, 7 and 8 and secure it with the three original screws.
