Lucci fini AIRFUSION Installationsanleitung

Installation Instructions
Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and follow all
instructions carefully before using the product. Please keep instructions for future reference.
Warranty
•
This light fitting is covered by a 3 year warranty. Please retain proof of purchase and evidence of installation by a
licensed electrician.
•
Warranty will be void if there is any damage due to improper usage or modification to the fitting.
IN EUROPE – If you are a European customer please contact the retail outlet where the light kit was purchased for
•
warranty service.
Installation requirements
•
Must be installed by a licensed electrician.
•
All wiring and installation of the light fitting must adhere to local and national wiring rules.
•
Select a suitable location for installation;
- This product is suitable for indoor use only.
- Ensure the fitting is not installed next to an air ventsystem
- When installing a fitting in an area prone to moisture, ensure that the area is well ventilated and an appropriately
rated exhaust fan is used if required. Damage or corrosion caused by moisture is not a product fault, and as
such is not covered under warranty.
•
Take care not to pull any electrical wires during unpacking as this may damage the connection.
•
Lay out all the components on a smooth surface and make sure there are no components missing before
assembling.
•
Check whether the fitting has been damaged during transport. Do not operate/install any product which appears
damaged in any way. Return the complete product to the place of purchase for inspection, repair or replacement.
•
Ensure power to the circuit you are working on has been switched OFF.
Installation directions
1. Remove all packaging material from the product.
2. Remove the bottom cover from the body of the fan.
3. Remove the light kit bracket (A) from the lamp body (B).
4. Install the light kit bracket (A) to the fan light bracket (C) by tightening the 3 screws provided (D).
5. Pull the L and N light wires (E) out from the fan body carefully.
6. Connect the L and N light wires to the terminal block (F) of the light kit according to the labels.
7. Attach the lamp body (B) to the light kit bracket (A) and secure by turning it clockwise.
1 | P a g e
AIRFUSION TYPE A LEDLIGHT KIT
SKU#211012, 211013, 211014, 211015
Rated Voltage 220-240V~ 50Hz
V 1 . 0 P u b l i s h e d o n 0 9 2 0 1 6
